1st Step: Mechanical Installation
1
Mark mounting holes for camera, transmitter, and antenna
2
Install the HD transmitter
3
Attach camera and antenna
Camera can be
installed upside
down
4
Connect the HD receiver antennas and mounting case
| Installation Quick Guide
Consider camera
cable length.
Use the dampers to avoid Jello
effect. Secure dampers with pins
and locking clips
Mount the antenna
on the back of the
drone
Optionally, fasten with
plastic ties
Recommended to
position antennas
straight up
HD receiver can be
mounted on a tripod
Snap the HD
receiver into the
mounting case
Doc P/N: 9040962 | Rev 01 | Printed 06/17/16
