MORTAR MIXER
6 CU. FT. - 8 HP BRIggs &
sTRATTOn
AssEMBly And OPERATIOn InsTRUCTIOns
IMPORTANT!
Your Warranty is
voided if:
You do not put Engine
oil in the Engine's
crankcase prior to its
first use. Never run the
Engine with low or no
Engine oil. Running
the Engine with low or
no oil will permanently
damage the Engine.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
TO PREVEnT sERIOUs InjURy, REAd And UndERsTAnd
All wARnIngs And InsTRUCTIOns BEFORE UsE.
©
Copyright
2007 by Harbor Freight Tools
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
EngInE
95906
®
. All rights reserved. No portion of this
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 95906 and is the answer not in the manual?

Questions and answers

Summary of Contents for Central Machinery 95906

  • Page 1 MORTAR MIXER 6 CU. FT. - 8 HP BRIggs & ® sTRATTOn EngInE Model 95906 AssEMBly And OPERATIOn InsTRUCTIOns IMPORTANT! Your Warranty is voided if: You do not put Engine oil in the Engine’s crankcase prior to its first use. Never run the Engine with low or no Engine oil.
  • Page 2: Specifications

    Write the product’s serial number in the back of the manual near the assembly dia- gram, or write month and year of purchase if product has no number. Keep this manual and invoice in a safe and dry place for future reference. REV 07f For technical questions, please call 1-800-444-3353. SKU 95906 Page 2...
  • Page 3: General Safety Rules

    Al- ways wear ANSI-approved safety goggles and a dust mask/respirator when using or performing maintenance on this tool. For technical questions, please call 1-800-444-3353. SKU 95906 Page 3...
  • Page 4: Specific Safety Rules

    Never run the Engine with low or no engine oil. Run- ning the Engine with low or no Engine oil will permanently damage the Engine. For technical questions, please call 1-800-444-3353. SKU 95906 Page 4...
  • Page 5 Care must be taken when backing up the Mortar Mixer. Only back up the Mixer on a straight path. If the Mixer is allowed to turn off the straight path while backing For technical questions, please call 1-800-444-3353. SKU 95906 Page 5...
  • Page 6 Use proper fuel storage and handling procedures. Always have multiple ABC class fire extin- guishers nearby. keep the Mortar Mixer, its Engine, and surrounding areas clean at all times. For technical questions, please call 1-800-444-3353. SKU 95906 Page 6...
  • Page 7: Mechanical Precautions

    PRECAUTIOn Prolonged exposure to high noise levels is hazardous to hearing. Always wear ANSI-approved hearing protection when operating or working around the Mortar Mixer when it is running. For technical questions, please call 1-800-444-3353. SKU 95906 Page 7...
  • Page 8 Frame Assembly (18). Then secure the Tow Shaft in place using the Hex Bolt (14) and Hex Nut (15) as shown in the following illustration. (see Figure C, next page.) For technical questions, please call 1-800-444-3353. SKU 95906 Page 8...
  • Page 9: Operating Instructions

    Drum rotating. To rotate the Drum, turn the Clutch Lever (19) to the right. Do not turn off the Mortar Mixer while full of cement. (see Figure d.) FIgURE d dUMP HAndlE (60) ClUTCH lEVER (19) dRUM lATCH (20) dRUM lOCk (72) For technical questions, please call 1-800-444-3353. SKU 95906 Page 9...
  • Page 10: Inspection, Maintenance, And Cleaning

    Before performing any inspection, maintenance, and cleaning, turn off the Engine and disconnect the Spark Plug Wire from the Spark Plug to prevent accidental starting. Then, allow the Engine to completely cool. For technical questions, please call 1-800-444-3353. SKU 95906 Page 10...
  • Page 11 Using a suitable solvent, thoroughly clean the Bearing (7), Oil Seal (10), Castle Nut (12), Cotter Pin (13), and the rest of the parts of the Hub assembly of all old For technical questions, please call 1-800-444-3353. SKU 95906 Page 11...
  • Page 12 (2) gREAsE FITTIng (lUBRICATE EVERy 90 dAys) lUg nUT (9) HUB (7) BEARIng (11) OIl sEAl (10) wHEEl (8) CAsTlE nUT (12) dUsT CAP (91) COTTER PIn (13) For technical questions, please call 1-800-444-3353. SKU 95906 Page 12...
  • Page 13: Parts List

    Tow Chain Flat Key (6.3x50) Frame Assembly Engine Pulley Clutch Lever Middle Large Pulley Drum Latch Middle Shaft Bolt (M12x150) Flat Key (8x115) Small Handle Sleeve Hex Bolt (M12x35) REV 07f For technical questions, please call 1-800-444-3353. SKU 95906 Page 13...
  • Page 14: Please Read The Following Carefully

    BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. REV 07f For technical questions, please call 1-800-444-3353. SKU 95906 Page 14...
  • Page 15: Assembly Diagram

    AssEMBly dIAgRAM nOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. For technical questions, please call 1-800-444-3353. SKU 95906 Page 15...
  • Page 16: Limited 1 Year / 90 Day Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 For technical questions, please call 1-800-444-3353. SKU 95906 Page 16...
