aspenhome
ah
ITEM NO: I240-487-RIV
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
HARDWARE LIST:
Description
No.
Bolt Ø5/16"*1-1/4"
A
Lock Washer Ø5/16"
B
Flat Washer Ø5/16" *3/4"
C
D Allen Wrench 4mm
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/2
R
TV Frame w/TV Mount (for -455)
Quantity
Sketch
8 PCS
8 PCS
8 PCS
1 PC
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
TV Mount
Assembly instructions for the TV
mount are in the TV mount package.
Follow these instructions when
attaching TV mount and TV to the
TV frame.
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:
Description
No.
1
TV Frame
Metal Strip
2
3
TV Mount
Quantity
Sketch
1 PC
2 PCS
1 Set
05-03-2017
Advertisement
Summary of Contents for aspenhome I240-487-RIV
-
Page 1: Assembly Instructions
ASSEMBLY INSTRUCTIONS ITEM NO: I240-487-RIV TV Frame w/TV Mount (for -455) Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. TV Mount Assembly instructions for the TV mount are in the TV mount package. - Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I240-487-RIV TV Frame w/TV Mount (for -455) STEP 1: Attach the metal strips to inner sets of threaded inserts on the chesser by using 4 bolts (A), lock washers (B) and flat washers (C). See below. Do not tighten the bolts completely.
