Summary of Contents for SL ZERO EDGE PRO

  • Page 1 ZERO EDGE PRO Owner’s Manual INSTALLERS: PLEASE BE SURE TO LEAVE THIS MANUAL WITH THE OWNER. THANK YOU!
  • Page 2 ZERO EDGE PRO APPLY S/N STICKER HERE LIMITED ONE YEAR WARRANTY ON SCREEN INNOVATIONS PRODUCTS Screen Innovations warrants its products, to the original purchaser only, to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase by the original purchaser provided they are properly oper- ated according to Screen Innovations’...

  • Page 3: Table Of Contents

    ZERO EDGE PRO SUGGESTED PROJECTOR PLACEMENT ZERO EDGE PRO Table of Contents SUGGESTED PROJECTOR PLACEMENT ............. 5 STANDARD FRAME PARTS LIST .

  • Page 4: Standard Frame Parts List

    ZERO EDGE PRO STANDARD FRAME PARTS LIST (LED Lights Only) STANDARD PRE ASSEMBLED 1 1/2’’ or 2’’ 1/2’’ Small trim trim option option Hardware Kit STANDARD Wall Brackets Mounting 4X Thick Corner 4X Thin Corner 1/4-20 x 1/4’’ Screws Brackets...

  • Page 5: Standard Frame Assembly

    STANDARD FRAME ASSEMBLY STANDARD STANDARD If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately. See page 46 for IP lighting Instructions. Flying Mount Only LED IR Controlled Only Thick Bracket Thin Bracket LED Remote 2X Flown Screen 2X Flown Ceiling...
  • Page 6 NOTE: If using AT or Maestro material then check to make sure the channel nuts are installed in the inner channel before proceeding. STANDARD STANDARD A = B Measure the diagonals to check if frame is square. If one diagonal is longer then push on the corners at that diagonal.

  • Page 7: Split Frame Parts List

    SPLIT FRAME PARTS LIST (LED Lights Only) SPLIT SPLIT If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately, see page 46 for IP lighting Instructions. Flying Mount Only LED IR Controlled Only LED Remote 2X Flown Screen 2X Flown Ceiling...

  • Page 8: Split Frame Assembly

    SPLIT FRAME ASSEMBLY NOTE: If using AT or Maestro material then check to make sure the channel nuts are installed in the inner channel before proceeding. SPLIT SPLIT Thick Bracket Thin Bracket Insert the thin corner brackets into the outside channels and the thick corner brackets into the inside channels of the vertical frames.
  • Page 9 SPLIT SPLIT A = B Measure the diagonals to check if frame is square. If one diagonal is longer then push on the corners at that diagonal. Tighten all set screws once the diagonals are equal to within 1/8’’. Make sure the points on the frame pieces line up. Then finger tighten 2 of the set screws to lock in the corners.

  • Page 10: Led Lights Attachment

    LED LIGHTS ATTACHMENT ZERO EDGE PRO ZERO EDGE PRO If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately, see page 50 for IP lighting Instructions. NOTE: Steps 1 and 2 will have already been completed if possible to be shipped that way.

  • Page 11: Black Diamond Or Short Throw Attachment

    ZERO EDGE PRO BD or ST BLACK DIAMOND OR SHORT THROW ATTACHMENT Material? Black diamond and short throw material are highly sensitive. Take care to not bend or crease the material as you unroll it. BLACK DIAMOND or SHORT THROW Wear gloves when handling material.
  • Page 12 BD or ST BD or ST DO NOT drop the frame onto the screen material. Frame must be gently set down onto the screen material to avoid denting the material. Remove and discard the black retaining bumpers then spread out the posts so that they align with the attaching bands.

  • Page 13: Slate Or Pure Attachment

    SLATE OR PURE ATTACHMENT BD or ST SLATE or PURE As you continue to attach the bands make sure the material is centered about the frame. This is easy to tell by making sure the edge of the material is flush with the edge of the frame. Attach one band in the middle of all four frame pieces.
  • Page 14 SLATE or PURE SLATE or PURE Attach the snaps at the middle and then work your way towards the ends on all 4 sides of the screen material. Remove and discard the black retaining bumpers then spread out the posts so that they aligning with the snaps on the screen material.

  • Page 15: Black Backer Attachment

    BLACK BACKER ATTACHMENT SLATE or PURE MAESTRO ATTACHMENT MAESTRO For AT Material Only Acoustically Transparent (AT) materials come with a black backer that must be installed to eliminate shine through. Wear gloves when handling material. Carefully unroll the screen material out onto a clean floor.
  • Page 16 MAESTRO MAESTRO Carefully lay the frame onto the screen material. Center the frame about the screen material. Remove and discard the black retaining bumpers then spread out the posts so that they aligning with the holes in the screen material. Put one end of the bungee through the hole in the material and place over the post while holding the other end.

  • Page 17: Small Trim Attachment

    MAESTRO ZERO EDGE PRO 1/2’’ SMALL TRIM Attach the bungees at the middle and then work your way towards the ends on all 4 sides of the screen material. Check to make sure the screen material is flat and adjust the bungee positions if necessary to flatten the screen material.
  • Page 18 SMALL TRIM ATTACHMENT SMALL TRIM SMALL TRIM Velvet on trim is delicate, handle with care. Install trim with screen flat on floor, NOT when screen is vertical. Split Frame Only Black Diamond only Attach the horizontal trim pieces. Align and secure the corners with the 1/4-20 x 1/4’’ screws as shown.

  • Page 19: Medium Or Large Trim Attachment

    MEDIUM OR LARGE TRIM ATTACHMENT MEDIUM or LARGE TRIM MEDIUM or LARGE TRIM Velvet on trim is delicate, handle with care. Install trim with screen flat on floor, NOT when screen is vertical. Split Frame Only Black Diamond only Loosen the screw on the corner plate, slide over to the corner, and hold the corners together while tightening the screw to secure the well aligned corners.

  • Page 20: Logo Attachment

    ZERO EDGE PRO ZERO EDGE PRO TRIM REMOVAL LOGO ATTACHMENT Attach the logo to the trim by holding it at the middle of the horizontal trim and letting Disconnect the trim at the corners by either removing the screw or loosening the corner the magnet pull it to and attach to the back of the trim.

  • Page 21: Wall Installation

    ZERO EDGE PRO WALL INSTALLATION WALL MOUNT WALL MOUNT TOP OF VIEWING LEVEL " (9.5 cm) FLYING MOUNT TOP OF VIEWING " (12.1 cm)

  • Page 22: Flown Installation

    FLOWN INSTALLATION WALL MOUNT FLYING MOUNT 100 lbs 100 lbs (45.3 kg) (45.3 kg)

  • Page 23: Ir Lighting Hex Codes

    IR LIGHTING HEX CODES ZERO EDGE PRO IR Controlled Option Only FLYING MOUNT 20 13 20 13 20 13 20 13 5C A3 5D A2 41 BE 40 BF 20 13 20 13 20 13 20 13 58 A7 59 A6...

  • Page 24: Ip Controlled Lighting Setup

    IP CONTROLLED LIGHTING SETUP ZERO EDGE PRO Screen Innovations LED IP Setup Instructions NOTES: Backlight IP Option Only Before attempting to connect your LED IP to Phillips Hue, ensure that the Hue Bridge is powered on and connected to the local WIFI network.
  • Page 25 NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com...
