banks 64268 Owner's Manual & Safety Instructions

2-in-1 flooring air nailer/stapler
Hide thumbs

Advertisement

Quick Links

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2018 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
18a
64268

Advertisement

loading
Need help?

Need help?

Do you have a question about the 64268 and is the answer not in the manual?

Questions and answers

Summary of Contents for banks 64268

  • Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. Visit our website at: http://www.harborfreight.com 64268 Email our technical support at: productsupport@harborfreight.com When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Table Of Contents

    National pipe thread, straight NIOSH-approved dust mask/respirator. WARNING marking concerning WARNING marking concerning Risk of Eye Injury. Wear ANSI-approved Risk of Explosion. safety goggles with side shields. Table A: Symbol Definitions Page 2 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 3 Tool and a hard hat must be used for the to react and result in a risk of injury to persons. applicable conditions. Wear heavy- duty work gloves during use. Item 64268 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4 Always verify prior to using the tool that the air source has been adjusted to the rated air pressure or within the rated air-pressure range. SAVE THESE INSTRUcTIONS. Page 4 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 5 Do not attempt to discharge fasteners into surfaces too hard to penetrate. Do not drive fasteners on top of other fasteners, or at too steep of an angle. Fasteners can ricochet causing personal injury. Item 64268 For technical questions, please call 1-888-866-5797. Page 5...
  • Page 6 If you feel any symptoms related to vibration (such explained in this manual. If abnormal as tingling, numbness, and white or blue fingers), vibration occurs, stop immediately. seek medical advice as soon as possible. SAVE THESE INSTRUcTIONS. Page 6 For technical questions, please call 1-888-866-5797. Item 64268...

  • Page 7: Specifications

    16 Gauge, 1-1/2"–  2 " Long, Nail Type Cleat Nail 15-1/2 Gauge, 1"–  2 " Long, Staple Type 1/2" Crown Staple 100 Cleat Nails (side loading) or Magazine Capacity 80 Crown Staples (top loading) Item 64268 For technical questions, please call 1-888-866-5797. Page 7...
  • Page 8 Handle Head cap Air Inlet plug Latch Moveable Magazine Fixed Magazine Spacer Page 8 For technical questions, please call 1-888-866-5797. Item 64268...

  • Page 9: Setup

    Tool is disconnected from the air supply. However, it is a good safety measure to attempt to discharge the Tool in a safe fashion after disconnecting to ensure that the Tool is disconnected and unpowered. Item 64268 For technical questions, please call 1-888-866-5797. Page 9...
  • Page 10 Page 10 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 11 Item 64268 For technical questions, please call 1-888-866-5797. Page 11...

  • Page 12: Operation

    Spacer with the three threaded mounting holes. 4. Set the Tool on its side to expose the three Screws. 7. Secure the Spacer to the Tool, using the three Screws. Page 12 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 13 Blade Guide and Magazine. clean external surfaces with clean, dry cloth. Hammer e. Store indoors out of children’s reach. previously Installed Boards Head Spacer Wood Board Being Subfloor Installed Item 64268 For technical questions, please call 1-888-866-5797. Page 13...

  • Page 14: Maintenance

    Maintain the lubricator's oil level. Drain the moisture filter regularly. Performing routine maintenance on the air supply will allow the Tool to operate more safely and will also reduce wear on the Tool. Page 14 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 15 9. If you are unable to clear the fastener jam using the method prescribed above, the Tool should be taken to a qualified service technician for proper servicing. Item 64268 For technical questions, please call 1-888-866-5797. Page 15...
  • Page 16 3. Replace damaged components. older tools.) 4. Dirty, worn or damaged valve. 4. Clean or replace valve assembly. Follow all safety precautions whenever diagnosing or servicing the Tool. Disconnect air supply before service. Page 16 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 17 Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 64268 For technical questions, please call 1-888-866-5797. Page 17...

  • Page 18: Parts List And Diagram

    Screw M6  x   1 6 Handle Spacer for 3/4" boards Air Inlet Plug Spacer for 1/2" boards Nut M6 Screw M6  x   1 2 Spring Pin 3  x   2 0 Hammer Page 18 For technical questions, please call 1-888-866-5797. Item 64268...
  • Page 19 Assembly Diagram Item 64268 For technical questions, please call 1-888-866-5797. Page 19...

  • Page 20: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
