Summary of Contents for Coros Intelligent helmet
- Page 1 www getcoros com...
- Page 3 Please install the controller properly before use . The product can realize online upgrade via dedicated COROS Application. Do not cut off the power or force the product off in the course of upgrading, otherwise, it might lead to booting failures ...
-
Page 4: Maintenance
Maintenance Helmet can be seriously damaged by substances such as petrol, paint, adhesives or cleaning agents. The damage sometimes may be invisible. Clean it with mild soap and water only. Storage Keep the helmet far away from high temperatures as the shell might be damaged when the environmental temperature surpasses 65.5 degrees. - Page 5 About COROS Helmet Just via simple settings, COROS helmet can be transformed to an intelligent helmet Indicating light Micro USB interface Power key Bone conduction headset Microphone...
- Page 6 Features Voice navigation Music Player Ride Data Acquisition Walkie and talkie Receiving calls...
-
Page 7: Quick Charge
Use COROS Helmet Quick Charge To charge the helmet, please open the Micro USB protective cover first at the back of the helmet, and then plug the data line in the Micro USB interface. Note: indication of charging status is as below... - Page 8 Starting up Before initial use of the helmet, please wake it up via charging. When you open the protective cover at the back of the helmet, you can see interfaces as indicated in the chart right side, press the power key and you can see the green light on which indicates the helmet has been successfully turned on.
- Page 9 Note: key-press modes and functions of indicating light described as below: Key-press modes Indicating light Function definition Press and hold Press and hold Press Green Blue for 7 5 seconds for 3 seconds Booting Wake up Shutdown Reset Slow Working status flashing Slow Non-working status...
-
Page 10: Quick Settings
Settings 1) Bluetooth pairing After powering on the helmet, turn on Bluetooth in your phone to enter the Bluetooth Pairing interface, find OTHER DEVICES, and select Coros Helmets Bluetooth " " Now discoverable as Jack . MY DEVICES Connected Coros Helmets... - Page 11 1)Download the Coros Helmet APP The product supports only iOS 7.0 and above. Option 2: Scan Quick Response code > Option 1: Search and Download> Search and find the appliation Coros Helmet in Apple Store, download it and save it...
- Page 12 Connect to COROS smart devices CM CC 92 % 11 12 Run the application Coros Helmet , select corresponding smart devices under the Device List. Device List BLE EF272B...
- Page 13 4)Match the controller Tap on Controller under Device interface to enter the Match interface, tap on Match and then press and hold any key on the controller until the SUCCESS MATCH popup.
- Page 14 Installing the controller Prepare the controller holder and the rubber rings rubber rings well, and then find a proper location from the bicycle handlebar. Make the rubber rings diagonal to fix the controller holder onto the handlebar as Chart B indicated, after the fixing completed, it should be look like as shown in Chart C.
- Page 15 Note: key press modes and corresponding functions described as below.。 Functions Icons Key-press mode Click Answer / hang up; Turn on / off walkie and talkie Click Turn On/Pause the Music Player; Volume increase for phone calls or walkie and talkie; Mute incoming calls Click Next Track;Volume decrease for phone calls or walkie and talkie;...
-
Page 16: Optional Accessories
5)Optional accessories The walkie and talkie is an optional accessory, please choose it based on your own need. A.Startup the walkie and talkie The icon (Icon 3) is power key, press and hold it for 2s to turn on the device B.Match the walkie and talkie Press and hold the icon (Icon 4) to enter the Bluetooth... - Page 17 Note: keys,key-press durations and corresponding functions described as below. K eys Indicating light Power key Bluetooth key Functio n definition Press and Press and hold Press and hold Green hold for 2s for 5s for 2s Charging Chargecomp leted Ch arging Power on Power off On for 2s...
-
Page 18: Warranty
Warranty COROS warrants to the original purchaser of this product that the product is free of defects in materials and workmanship for a period of one year from the original date of purchase. This warranty does not apply to defects of physical damage resulting from abuse, neglect, improper repair, improper fit, alterations, or use unintended by the manufacturer. - Page 19 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 20 www getcoros com www getcoros com www getcoros com www getcoros com...
