Summary of Contents for Freedocast Freedocast Pro

Page 1 User manual...
Page 2 Welcome Thank you for choosing Freedocast PRO Go Live Now !
Page 3: Table Of Contents
Contents What's in the Package Device description LED Status Go Live with Freedocast Pro Register your Freedocast Pro Device Download Freedocast Pro app Conﬁgure your Freedocast Pro Device Connect Device to App ( Android ) Connect Device to App ( iOS )
Page 4 Contents Encoder speciﬁcations Battery speciﬁcations Power adapter speciﬁcations Warranty Battery model, Liability Device Software update...
Page 5: What's In The Package
What's in the Package Freedocast Pro Device Hot Shoe Ethernet Cable HDMI Cable Adapter Remote...
Page 6: Device Description
Device Description Adapter in AV out Ethernet 12V-1.5A Power button HDMI out HDMI in Mic in/ out On/ Oﬀ...
Page 7 Device Description USB 2.0 USB 3.0 Reset TF Card slot...
Page 8: Led Status
LED Status Power Battery Network LED Name Status LED Color Green 1. Power Standby 2. Battery Fully charged Green Charging Green blinking Adapter connected above 40% Green 2. Battery below 40% , above 20% Adapter not connected below 20% Red blinking Connected Green Streaming...
Page 9: Go Live With Freedocast Pro
Go Live with Freedocast Pro 1. Create a Freedocast account 2. Register your Device 3. Download Freedocast Pro App 4. Conﬁgure your Device 5. Connect Device to App ( Android/ IOS ) 13-16 6. Start a Live broadcast...
Page 10: Register Your Freedocast Pro Device
1. Create a Freedocast account Register/ Login to your Freedocast account at www.freedocast.com 2. Register your Device Go to Dashboard >> Device Management & click on Add Device Now enter the Box ID (a six digit alpha-numeric code visible at the back of device) &...
Page 11 Enter a name for the Device & Click Next to get the Pairing ID Enter Device Name Pairing ID Note : Pairing ID will be used to connect Freeodcast Pro App to Device...
Page 12: Download Freedocast Pro App
3. Download Freedocast Pro App Freedocast Pro App enables you to control the Freedocast Pro device & start Live broadcasting Broadcast simultaneously to multiple platforms like FB Live, YouTube Live, Periscope etc. Provide your users Live HD viewing experience and control the quality easily via...
Page 13: Conﬁgure Your Freedocast Pro Device
4. Conﬁgure your Device Push the Power button to turn on the device Power Button POWER HDMI OUT AV OUT HDMI IN ETHERNET 12V-1.5A HDMI IN Connect the Camera or Video Source to HDMI-IN...
Page 14: Connect Device To App ( Android )
5. A. Connect Device to App Android Turn on your Device and open the Freedocast Pro app Turn ON Bluetooth on your mobile phone (This is required to pair with Freedocast Device - supports Bluetooth 4.0 + ) 2 . Select your device’s box ID & click on...
Page 15 4. Select your mode of connection for the Device & click on Next ( a ) Wi-Fi Enter the wiﬁ password ( b ) Ethernet Note : Your device will act like a hotspot You are successfully connected to your Freedocast Pro device...
Page 16: Connect Device To App ( Ios )
5.B. Connect Device to App Turn on your Device and open the Freedocast Pro app Note: Your Freedocast device has created a temporary hotspot, Connect to it by following the instructions given below. Go to your iPhone settings >Wi-Fi Connect to the hotspot prompted by the Freedocast Pro device.
Page 17 Select your mode of connection by tapping on (a) Wi-Fi (b) Ethernet Enter the Pairing ID & click on CONNECT (Refer pg10 for Pairing ID) You are successfully connected to your Freedocast Pro device...
Page 18 Check Device Wi-Fi status To know your Device Wi-Fi network click on “Check Device Wi-Fi status” Enter your Box ID and click on Next ( Refer pg no 9 for Box ID ) 3. Follow the onscreen instructions to get connected with the Device...
Page 19: Start A Live Broadcast
Make sure your Freedocast Device is connected to a Camera or video source through HDMI IN (refer pg no 12) Open Freedocast Pro app and select your device on which you want to Go Live (refer pg13-Android | pg15- iOS ) 1.
Page 20: Encoder Speciﬁcations
Encoder speciﬁcations Video Encoder Items Speciﬁcations Standard H.264 Resolutions 320X240 TO 1920X1080 Bitrates 100 Kbps to 10 Mbps Proﬁles Baseline, Main and High Audio encoder Items Speciﬁcations Standard AAC-LC 32, 44.1 and 48 kHz Sample Frequency when digitized from analog source Channels 2 channels Stereo (L/R) Bitrates...
Page 21: Battery Speciﬁcations
Battery speciﬁcations Battery Pack IHO-4000 I Items Speciﬁcations Type Rechargeable lithium-ion battry Nominal Voltage 7.2V DC Nominal Capacity 3.6 V 2600 mAh Impedance ≤220mΩ Charging Cycles Approx.400 times Operating Temperatures 0～60℃ ≤1 month –20～45℃ ≤3 months 0～30℃ Storage temperature ≤1 year 15～25℃...
Page 22: Power Adapter Speciﬁcations
Battery Charger - SY6912 Main Board Built-in Items Speciﬁcations Rated Input 12V DC,1.5A Rated Output 8.4V DC,1.25A Charging Time Approx. 5~6 hrs Operating Temperatures 0~40℃ Power Adapter speciﬁcations Compact Power Adapter India : GSCI1500S012V18H/RJ-AS120150N102 US : GSCU1500S012V18N Items Speciﬁcations Rated Input 90-270V AC(50/60Hz) 0.5A Rated Output 12V DC,1.5A...
Page 23: Warranty
Warranty Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 24: Battery Model, Liability
In case a latest software version is available, it will either trigger the update automatically on switching ON or rebooting your device or on accepting the update request in the Freedocast Pro App. Software update progress is displayed as a pop up in your Freedocast Pro App.
Page 25 www.freedocast.com...
