- Page 2 Step 1: Open the Box. Step 2: Inside the box you will find the Pre-Assembled body of CODIBOT along with the Add-On packs, Connecting Wires, Nuts & Bolts. Take out the Main body along with the Connecting Wires. Step 3: Our first task will be to make CODI run, we will be testing its FEET.
- Page 3 Start making connections according to the diagrams given below. You don’t have to worry about connecting the H- Bridge and motors, they are already connected just focus on Arduino and H-Bridge. Make the following connections between H-Bridge & Arduino (Refer to the Diagram above): •...
- Page 4 Once Connected it should look something like this: Step 4: Our next step is to tinker with CODI’s BRAIN so that we can teach him to run, to do that we will have to download the program called ARDUINO from the link provided as well as the graphical plug-in called ARDUBLOCK that will help us in coding CODI’s Brain.
- Page 5 This is ArduBLOCK: 1. Click on Yellow “Control” Panel on the left side, it will open up a menu. Select the “do loop” panel, drag and drop it on the Big grey screen. 2. Now click on the Dark Blue “Pin” Panel and drag & drop the “Set Digital Pin” Panel on the grey screen and match it up with the “do loop”...
- Page 6 3. Repeat Step B, again & again such that four “Set Digital Pin” panels are stacked on top of each other. 4. Go to the first (top most) “Set Digital Pin” Panel, click on the light pink box beside the “#” sign (Pin Number) and set the pin number to 6.
- Page 7 15. The last two pins i.e. the “Set Analog Pins” have values 255, no need to change that. 16. Now click on the “Upload to Arduino” button, make sure your CODIBOT is connected to your computer and the CODI’s Power Button is set to OFF. The Arduino will light up none the less.
- Page 8 17. The Arduino Screen will show the upload status of the code to the CODI’s BRAIN (notice the green bar). Once the upload is complete, turn ON the power button and watch magic happen. The CODI’s tires will start to move forward.
-
Page 9: Battery Instructions
Battery Instructions: • On a full charge, the battery lasts for one hour. • It will take 2 to 3 hours to fully charge the battery. • Do not over charge the battery, it will result in damage to the battery and might decrease its life and capacity.
