Omniwash ST series Instruction Manual

Industrial glass and dishwasher, undercounter

Advertisement

EN
INSTRUCTION MANUAL MOD. ST – FOR INSTALLER
INDUSTRIAL GLASS AND DISHWASHER, UNDERCOUNTER
FOR EXCLUSIVE USE OF TECHNICALLY QUALIFIED PERSONNEL
CAREFULLY READ THESE INSTRUCTIONS BEFORE PROCEEDING WITH THE INSTALLA-
TION AND OPERATION OF THE MACHINE.
ANY INSTALLATION, ALTERATION OR MODIFICATION THAT DOES NOT COMPLY WITH
THE STANDARDS SPECIFIED IN THIS MANUAL MAY CAUSE A MALFUNCTION OR DAMA-
GE TO THE MACHINE. THE WARRANTY WILL NOT BE CONSIDERED VALID AND THE
COMPANY WILL NOT BE LIABLE IN THE EVENT OF INCORRECT USE OR FOR ANY DA-
MAGE CAUSED BY NEGLIGENCE OR FAILURE TO FOLLOW THESE INSTRUCTIONS.
1.1
Installation:
1.2
Modifications:
1.3
Defects and malfunctions:
1.4
Repairs and Spare Parts:
SUMMARY
Commissioning
Adjusting the dosing
INSTRUCTION MANUAL INDUSTRIAL DISHWASHER
- ENGLISH -
Attention:
The Installation of the machine must be performed only by authorized personnel and
in compliance with the laws in force and these instructions.
The manufacturer reserves the right to modify the equipment or the content of instruc-
tions, without prior notice.
In the event of a defect or malfunction, the main electricity supply and water supply
MUST be disconnected not only from the machine but even from the mains.
The product must be repaired only by authorized personnel, only using original spare
parts.
DECLARATION OF CONFORMITY
EUROPEAN DIRECTIVE
2002/95/CE RoHS
- 1 -
Page 02
Page 03
Page 05
Page 06
Page 07
Page 09
Page 11
