Mercury 450.007UK User Manual

A stylish, height-adjustable pedestal fan with 3 speed settings, oscillating head and tilt control. Ideal for home and work,
it is quiet yet powerful and offers flexible height, directional adjustment and an attractive chrome finish. The steel mesh
guard is easy to detach and replace, allowing for easy cleaning of the interior and fan blades as required.

Specification:

Cable length
Power output
Blade diameter
Mains power
Height adjustment
Dimensions
Weight

Features:

• Quiet yet powerful 50W motor
• 3 speed settings
• Attractive chrome finish
• Versatile height, swivel and tilt adjustments
•
Weighted circular base for extra stability

Assembly diagram:

1. Front grille
2. Fan blade
3. Fan blade screw
4. Rear grille fixing screws
5. Rear grille
6. Motor shaft
7. Speed control
8. Fan motor
9. Mains lead
10. Tilt adjustment screw
11. Inner tube
12. Height adjustment screw
13. Telescopic stand
14. Fan base
15. Base weight
16. Clamping washer
17. L-shaped lock screw
Assembling the base (see Fig. 1):
1. Unscrew the L-shaped locking screw (17) and remove it from the base (14) along with the clamping washer (16).
2. Now place the base weight (15) in the centre of the underside of the fan base (14) and the clamping washer (16)
into the centre of the base weight.
www.avsl.com
16 Inch Chrome Pedestal Fan
1.6m
50W
400mm
220-240V
970mm to 1230mm
1230 x 450 x 400mm
6.4 kg
Order ref: 450.007UK
User Manual
450.007UK User Manual
