Notice for Use
Thank for choosing Eleaf products! Please read this
manual carefully before use so as to use correctly. If you
require additional information or have questions about the
product or its use, please consult your local agents, or visit
our website at www.eleafworld.com.
Product Introduction
LCD Meter, an e-cigarette testing tool, endows with
testing atomizer resistance and battery voltage and
wattage. With plugging it on the e-cigarette atomizer
and battery, you can read the atomizer resistance or
battery voltage/wattage easily from its glass window, the
LCD Screen. What the wonder is that you can vapor
while testing.
Key Specifications
Input voltage:2.5V~6.5V
Testable wattage:≤100W
Maximum current:≤10A
Resistance range:0.5~10Ω
Output voltage:2.5~6.5V
How to assemble
a) No-load Condition:
When only connecting to battery, press the battery
button, the LCD Screen will first display "No
Ω"(meaning no resistance), then the virtual voltage of
this battery.
b) On-load Condition:
When connecting to battery and atomizer in the
same time, press the button, the LCD Screen will first
display the virtual atomizer resistance, then the
current voltage and wattage after 1 second. Less the
battery power is, lower the voltage and wattage are.
LCD Meter
User Manual
Advertisement
Table of Contents
Summary of Contents for Eleaf LCD Meter
- Page 1 Product Introduction LCD Meter, an e-cigarette testing tool, endows with testing atomizer resistance and battery voltage and wattage. With plugging it on the e-cigarette atomizer...
- Page 2 0.5Ω, the LCD Screen will show ”E1” to raise an alarm. Precautions a) Only have your LCD Meter repaired by Eleaf. Do not attempt to repair the unit by yourself as damage or personal injury may occur. b) Do not leave the LCD Meter in high temperatures or damp conditions, otherwise it may be damaged.
