SpyCentre.com Spy Shop - Since 1993
6744– 19 Hour Audio Pen

How to Charge the Battery:

1. Connect the audio recorder to a PC or USB power supply with the provided AUX to USB cable
2. Takes 2 hours to fully charge
3. Solid light = Charging
4. A flashing light = Fully Charged
NOTE: A solid light will be present when device is connected to a PC

How to Record an audio file:

1. The middle of the pen unscrews exposing the the USB connector as well as a toggle switch for either Con-
tinuous or Voice Activated recording
2. Underneath the USB metal prongs are two hard to see symbols (-) & (..) with a toggle switch at the base
3. If the toggle switch is turned towards the
4. If the toggle switch is turned towards the
5. Near the top of the pen is a silver band that connects to the silver pen clip. You will see a white dot located
in the silver band.
6. Turn the black cap piece above the silver band 1/4inch clockwise to Activate the device. You will see the
white dot located in the silver band turn black.
7. Once finished turn the black cap piece ¼ inch counter clockwise to finish the recording
8.Wait 5 seconds before making another recording
NOTE: If the device runs out of power during the recording, it will finalize and save the file before the
battery dies
Also NOTE: The device can record while plugged in for consistent power. In order to do this Activate
the device in either recording mode and then connect the device to a powered USB port.

How to Playback files on a PC:

1. Connect the device to the USB port of the computer
2. When connected the PC will recognize the device as a removable disk
3. Open the VOICE folder
4. Click the file you wish to play

How to Playback files on a MAC:

1. Connect the device to the USB port of the computer
2. When connected the MAC will recognize the device as a removable disk
3. Open the VOICE folder
4. Click the file you wish to play
19 HOUR AUDIO PEN RECORDER
(-)
symbol the device is in Continuous recording mode
(..)
symbol the device is in Voice Activated recording mode
Monday - Saturday 10AM to 6PM CST

QUICK START GUIDE

Toll Free # 1-800-292-7748

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6744 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spycentre Security 6744

  • Page 1: Quick Start Guide

    QUICK START GUIDE SpyCentre.com Spy Shop - Since 1993 Toll Free # 1-800-292-7748 6744– 19 Hour Audio Pen How to Charge the Battery: 1. Connect the audio recorder to a PC or USB power supply with the provided AUX to USB cable 2.
  • Page 2 19 HOUR AUDIO PEN RECORDER QUICK START GUIDE SpyCentre.com Spy Shop - Since 1993 Toll Free # 1-800-292-7748 How to Playback files on a Google Chrome Book: 1. Connect the device to the USB port of the computer 2. A pop up menu may occur, if so select “View Files” 3.
  • Page 3 19 HOUR AUDIO PEN RECORDER QUICK START GUIDE SpyCentre.com Spy Shop - Since 1993 Toll Free # 1-800-292-7748 How to Download the Time/Date Stamp file: Windows only 1. Open a new web Browser 2. Go to https://spycentre.com/products/pro-usb-flash-drive-audio-recorder 3. Click on the Blue Support Tab located above the Review Video but below the Pictures 4.
  • Page 4 19 HOUR AUDIO PEN RECORDER QUICK START GUIDE SpyCentre.com Spy Shop - Since 1993 Toll Free # 1-800-292-7748 VLC Media Player (recommended for optimal usage) How to download and use VLC media (Windows) 1. www.videolan.org 2. Click“download VLC” 3. If it does not automatically begin downloading, press the Click here and select one of the mirrored sites 4.
