Summary of Contents for megabyte Logistic Tray L2-U
- Page 1 Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 Logistic Tray L2-U User Manual Rev. 3.0 Model: Logistic Tray L2-U Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)
-
Page 2: Table Of Contents
Updated on 7NOV 2016 Table of Content FCC statement..................... 3 CE statement ....................... 3 Chapter 1 Introduction of Logistic Tray L2-U ..........4 Overview of Logistic Tray L2-U ............4 Ports Description ................5 Indicators LEDs in Logistic Tray L2-U ..........5 Antenna for Logistic Tray L2-U ............ -
Page 3: Fcc Statement
Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 FCC statement FCC NOTICE: To comply with FCC part 15 rules in the United States, the system must be professionally installed to ensure compliance with the Part 15 certification. It is the responsibility of the operator and professional installer to ensure that only certified systems are deployed in the United States. -
Page 4: Chapter 1 Introduction Of Logistic Tray L2-U
• The Logistic Tray L2-U Intelligent RFID Reader supports protocols, UHF CLASS 1 GEN2 EPC C1G2/ISO 18000-6C, 902-928 MHz RFID frequency band in United States. -
Page 5: Ports Description
Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 1.2 Ports Description The Logistic Tray L2-U has several types of input/output port: Items no. Name Description DC jack 6.5V/3A dc power supply input USB port One standard USB port... -
Page 6: Indicators Leds In Logistic Tray L2-U
Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 1.3 Indicators LEDs in Logistic Tray L2-U The Logistic Tray L2-U has different LEDs to indicate the reader status. Items no. Name Description Red LED Powered On but USB not connect... -
Page 7: Antenna For Logistic Tray L2-U
User Manual Rev. 3.0 Updated on 7NOV 2016 1.4 Antenna for Logistic Tray L2-U There are two identical antennas are used with Logistic Tray L2-U. The following antennas are used for Logistic Tray L2-U: : antenna gain = 0dBi RFID NEAR FIELD FLAT PANEL ANTENNA Technical Contacts and Enquiry: jimmywong@myndar.com... -
Page 8: Specification
Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 1.5 Specification: Item Specification 1 power key button Input 1 USB port Red LED indicate for Powered On but USB not connected Indicator Blue LED indicate for Powered On and USB Connected Connectivity USB2.0 6.5V 3A ac to dc power adapter... -
Page 9: Chapter 2 Installation Of Logistic Tray L2-U
Updated on 7NOV 2016 Chapter 2 Installation of Logistic Tray L2-U 2.1 Start-up Procedure of Logistic Tray L2-U This section explains how to set-up Logistic Tray L2-U and connect the Logistic Tray L2-U to your computer and antenna: Plug in the power adapter. -
Page 10: Environmental Requirements
Blue LED will be turned on. IV. Select the test tools or apps for application. V. Logistic Tray L2-U operates at UHF frequency band, FCC 902-928 MHz, SRRC 920-925 MHz and NCC 922-928 MHz); the setting depends on countries’ regulations. -
Page 11: Caution
Please read the information contained within this user manual prior to attempting installation and operation of the RFID Reader. Failure to install and operate the RFID Terminal (Logistic Tray L2-U) in accordance with the information contained in this manual may result in unsatisfactory performance. -
Page 12: Chapter 3 Demonstration Of Rfid Applications
Chapter 3 Demonstration of RFID Applications 3.1 Creating RFID Application with Logistic Tray L2-U Logistic Tray L2-U is an intelligent reader and compliance with EPC global C1G2/ISO 18000-6C , Users can develop own UHF RFID application on this platform. 3.1.1... -
Page 13: Chapter 4 Regulatory Information
- Consult the dealer or an experienced radio/TV technician for help. WARNING: DO NOT ATTEMPT TO SERVICE THE WIRELESS COMMUNICATION DEVICE YOURSELF. SUCH ACTION MAY VOID THE WARRANTY. THE LOGISTIC TRAY L2-U IS FACTORY TUNED. NO CUSTOMER CALIBRATION OR TUNING IS REQUIRED. CONTACT MEGABYTE LTD. TECHNICAL SUPPORT FOR INFORMATION ABOUT SERVICING YOUR WIRELESS COMMUNICATION DEVICE. -
Page 14: Ce Compliance
Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 This device must be used in fixed locations and in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. This device must not be co-located or operating in conjunction with any other antenna or transmitter 4.2 CE Compliance This device has been tested to and conforms to the regulatory requirements of the... - Page 15 Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)
-
Page 16: Chapter 5 Disclaimer Notice
Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 Chapter 5 Disclaimer Notice Disclaimer Notice The manufacturer shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material. -
Page 17: Chapter 6 Warranty
The Warranty Period shall not be extended by reason of any repair or replacement. Megabyte Ltd shall have no liability to the User for any damage to or defects in any of the Products caused by fair wear and tear, improper use, negligent handling, failure to observe... - Page 18 Logistic Tray L2U User Manual Rev. 3.0 Updated on 7NOV 2016 Chapter 7 Support Technical support/Sales Enquiry can be obtained from Megabyte Ltd. Please email to: jimmywong@myndar.com Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)
