megabyte mHand H3-B User Manual

Rev. 3.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
mHand H3-B
User Manual Rev. 2.0
Updated on 20May, 2016
mHand H3-B User Manual Rev. 3.0
Model: mHand H3-B
Technical Contacts and Enquiry: jimmywong@myndar.com
Website: www.myndar.com
1
(This user manual / product specification is subjected to be changed without prior notice)
P.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mHand H3-B and is the answer not in the manual?

Questions and answers

Summary of Contents for megabyte mHand H3-B

  • Page 1 H3-B User Manual Rev. 2.0 Updated on 20May, 2016 mHand H3-B User Manual Rev. 3.0 Model: mHand H3-B Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)

  • Page 2: Table Of Contents

    Updated on 20May, 2016 Table of Content FCC statement..................... 3 CE statement ....................... 3 Chapter 1 Introduction of mHand H3-B ............. 4 Overview of mHand H3-B .............4 Ports Description ................5 Buttons in mHand H3-B ..............6 Indicators LEDs in mHand H3-B ...........8 Specification: ................

  • Page 3: Fcc Statement

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 FCC statement FCC NOTICE: To comply with FCC part 15 rules in the United States, the system must be professionally installed to ensure compliance with the Part 15 certification. It is the responsibility of the operator and professional installer to ensure that only certified systems are deployed in the United States.

  • Page 4: Chapter 1 Introduction Of Mhand H3-B

    Chapter 1 Introduction of mHand H3-B 1.1 Overview of mHand H3-B: mHand H3-B is an UHF EPC C1G2 mobile RFID handheld with Bluetooth technology, the plug & play Bluetooth connectivity increases the flexible on the RFID stock-take through Bluetooth enabled mobile device. Lightweight and OS independent, the ergonomic design with enhanced reading sensitivity.

  • Page 5: Ports Description

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 1.2 Ports Description (1) Battery charging port Input port of the mHand H3-B: Items no. Name Description Micro USB jack 5V/2A dc power supply input Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com...

  • Page 6: Buttons In Mhand H3-B

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 1.3 Buttons in mHand H3-B (2) Power ON Button (3) Battery removable button Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)
  • Page 7 H3-B User Manual Rev. 2.0 Updated on 20May, 2016 (4) Reading Lock Key (5) Read Button Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)
  • Page 8 H3-B User Manual Rev. 2.0 Updated on 20May, 2016 Items no. Name Description Power ON Button Press to switch the device on Battery removable button Press to unlock battery Reading Lock Switch on to retain reading function Read Button...

  • Page 9: Indicators Leds In Mhand H3-B

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 1.4 Indicators LEDs in mHand H3-B (7), (8) The LEDs show the read Blue LED indicates button is pressed in operation Bluetooth is ON Orange LED indicates low battery (10)
  • Page 10 H3-B User Manual Rev. 2.0 Updated on 20May, 2016 The mHand H3-B has different LEDs to indicate the reader status. Items no. Name Description Blue and white LED Blue LED On means the BT is connected; (LED3) White LED On means the BT is turn on and ready to...

  • Page 11: Specification

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 1.5 Specification: Item Specification 1 power On button Input 1 read button Red LED stand for charging Orange LED stand for low battery indicator Blue LED stand for fully charged...

  • Page 12: Chapter 2 Installation Of Mhand H3-B

    Updated on 20May, 2016 Chapter 2 Installation of mHand H3-B 2.1 Start-up Procedure of mHand H3-B This section explains how to set-up mHand H3-B and connect the mHand H3-B to your computer: Power On the mHand by pressing the Power On button.
  • Page 13 BT address to pair. In general, the mHand BT name is called “ H3B_XXXXXXXXXXXXXX” IV. mHand H3-B operates at UHF frequency band, ranging from FCC 902-928 MHz, SRRC 920-925 MHz, KCC 917-920.8 MHz, ACMA 920-926MHz, MIC 916.8-923.4MHz); the setting depends on countries’ regulations.
  • Page 14 H3-B User Manual Rev. 2.0 Updated on 20May, 2016 “UniversalReaderAssistant” in the computer to control the mHand operation. VII. Set the “COM” number in the program which is generated after paired. The “COM” number can be found in the device manager in the computer.

  • Page 15: Environmental Requirements

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 2.2 Environmental Requirements The next table includes environmental requirements for the mHand H3-B. Choose a location that meets these requirements. Description Minimum Maximum Operating temperature 0ºC 40ºC Storage temperature -20ºC 60ºC...

  • Page 16: Caution

    Please read the information contained within this user manual prior to attempting installation and operation of the RFID Reader. Failure to install and operate the RFID Terminal (mHand H3-B) in accordance with the information contained in this manual may result in unsatisfactory performance.

  • Page 17: Chapter 3 Demonstration Of Rfid Applications

    Updated on 20May, 2016 Chapter 3 Demonstration of RFID Applications 3.1 Creating RFID Application with mHand H3-B mHand H3-B is an intelligent reader and compliance with EPC global C1G2/ISO 18000-6C , Users can develop own UHF RFID application on this platform. 3.1.1...

  • Page 18: Chapter 4 Regulatory Information

    - Consult the dealer or an experienced radio/TV technician for help. WARNING: DO NOT ATTEMPT TO SERVICE THE WIRELESS COMMUNICATION DEVICE YOURSELF. SUCH ACTION MAY VOID THE WARRANTY. THE MHAND H3-B IS FACTORY TUNED. NO CUSTOMER CALIBRATION OR TUNING IS REQUIRED. CONTACT MEGABYTE LTD.

  • Page 19: Ce Compliance

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 4.2 CE Compliance This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters "CE".

  • Page 20: Chapter 5 Disclaimer Notice

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 Chapter 5 Disclaimer Notice Disclaimer Notice The manufacturer shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.

  • Page 21: Chapter 6 Warranty

    The Warranty Period shall not be extended by reason of any repair or replacement. Megabyte Ltd shall have no liability to the User for any damage to or defects in any of the Products caused by fair wear and tear, improper use, negligent handling, failure to observe...

  • Page 22: Chapter 7 Support

    H3-B User Manual Rev. 2.0 Updated on 20May, 2016 Chapter 7 Support Technical support/Sales Enquiry can be obtained from Megabyte Ltd. Please email to: jimmywong@myndar.com Technical Contacts and Enquiry: jimmywong@myndar.com Website: www.myndar.com (This user manual / product specification is subjected to be changed without prior notice)
