Product Instructions
MCG-CC
Hand Compression Tool
MCG-CC hand compression tool: overview
A. Release strap
B. Top hatch
C. Frameset
D. Internal piston housing
E.
Release lever
F.
Plastic removal tool
G. Lever arm
Insert cross reference chart
Cable size
Interface
Top cable
insert
(black)
Bottom cable
insert
(black)
Interface
insert
15156-01 rev. A
Page 1
A
1/4"
All
DIN
©2017 JMA Wireless. All rights reserved. All trademarks identified by ® or ™ are registered trademarks, respectively, of JMA Wireless. All
specifications are subject to change without notice. See www.jmawireless.com for the most current information. Revised: January 12, 2017
B
C
E
F
G
1/2"
Mini DIN
N
(blue)
(blue)
D
4.3-10
No insert
No insert
7/8"
All
needed
needed
