THE
N EW
G ENERATION
I N
T ECHNOLOGY
Portable
S peaker
w ith
U SB/SD/MMC
I nputs
a nd
F M
R adio
w ith
L ED
D isplay
I. Operating Key:
1. Press
Key to PLAY/PAUSE
2. Press
key to go to next songs, press and hold 1-2 additional seconds to
forward.
3. Press
to go to previous songs, press and hold 1-2 additional seconds to
rewind.
4. Press V- to reduce volume, press V+ to increase volume.
5. Press "MENU" Key to adjust MP3/FM/AUX mode.
6. "ON-OFF": Power switch
NAS-‐3051
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for Naxa NAS-3051
Summary of Contents for Naxa NAS-3051
- Page 1 THE N EW G ENERATION I N T ECHNOLOGY NAS-‐3051 Portable S peaker w ith U SB/SD/MMC I nputs a nd F M R adio w ith L ED D isplay ...
- Page 2 II. Connections: 1.“5V DC” ：For power charging 2. “MICRO SD/TF”: Insert Micro SD (TF) memory card 3. “USB HOST”: Insert Flash USB Stick 4. “OUT” for line-out 5. “Aux-in” or “Line-in” III. Power Supply 1. USB 5V 2. Built-in lithium rechargeable battery 3.
- Page 3 Note: This speaker is not waterproof. Specification: Unit Measure 50*48*62MM Display Screen Battery 3.7V/500mAh rechargeable lithium battery LINE-IN Maximum Input (L)300mV+ R 300mV Output Power 2.5W MP3 Bits 8K bps-320K bps Signal to Noise Ratio 65dB Degree of Distortion < 0.55% Music Format -5 to 40 Degrees Centigrade Temperature...
