ENVIROLINK MANUAL (CONTINUED)

Programming the Skutt KilnMaster 700 for use with the EnviroLink

OP A (Option A)
When option A is selected Output 4 will turn on when a ConeFire Mode program is started. When the
program has run and the kiln has cooled to 150 °F output 4 will turn off.
When a Ramp/Hold program is entered it will ask whether you want the fan (or other accessory) on for
each segment you program. After you enter the hold time for each segment the display will show FAN
along with the number of the segment you are programming. Alternately it will flash the current setting,
either OFF or ON. To change the setting toggle it with the 1 key and press ENTER to select that setting.
OP b (Option B)
During a ConeFire program Output 4 will turn on when START is pressed. It will then turn off at 1450 °F.
It will turn back on when the kiln is cooling and the temperature drops below 1000 °F. It will then turn
off when the kiln cools to 150 °F.
When a Ramp/Hold program is entered it will ask whether you want the fan (or other accessory) on for
each segment you program. After you enter the hold time for each segment the display will show FAN
along with the number of the segment you are programming. Alternately it will flash the current setting,
either OFF or ON. To change the setting toggle it with the 1 key and press ENTER to select that setting.
OP C (Option C)
When Option C is selected Output 4 does not come on during any portion of a ConeFire Mode program.
When a Ramp/Hold program is entered it will ask whether you want the fan (or other accessory) on for
each segment you program. After you enter the hold time for each segment the display will show FAN
along with the number of the segment you are programming. Alternately it will flash the current setting,
either OFF or ON. To change the setting toggle it with the 1 key and press ENTER to select that setting.
ALR4 (Alarm 4)
This is the factory default setting. If Output 4 is not being utilized this is the setting that should be
selected. This feature can also control an external alarm or autodialer to initiate if an Error Code is
generated or if the internal temperature of the kiln reaches the temperature programmed for the ALARM
setting of the program. To deactivate the alarm press ENTER.
To select an option:
From IDLE Mode, Press MENU until the display reads CNFG (Configuration) and press
1.
ENTER.
Press MENU until the display reads OUT4 (Output 4). Press ENTER.
2.
Press MENU until you reach the option you want and press ENTER. (Do not select PCT)
3.
Caution : If you are using the EnviroLink with the original EnviroVent (motor mounts directly under
the kiln) then be sure to choose an option that ensures the fan stays on at temperatures above 2000 °F.
Long term exposure to high temperatures while the motor is not running may damage the motor.
