INSTALLATION INSTRUCTIONS
MSD Power Grid Power Module
ONLINE PRODUCT REGISTRATION: Register your MSD product online. Registering your product
will help in case of a warranty or recall. Go to www.msdperformance.com/registration.
Parts Included:
1-MSD Power Module
1-Main Wiring Harness
1-Mounting Kit
WARNING: During installation, disconnect the battery cables. When disconnecting the battery always
remove the Negative cable first and install it last.
OPERATION
The Power Grid Power Module contains four channels of programmable 20 Ampere solid state relays.
Each output can be controlled independently, or simultaneously, giving great flexibility. Each channel
can use Time, Engine Speed, or a Temperature sensor to activate fans, fuel pumps, or NOS systems.
The Power Grid's data logger within the PN7730 can record all functions of the Power Module.
All four outputs of the Power Module have the identical properties and features.
WIRING
Power Grid
When using the Power Module (PN7764)
with the Power Grid (PN7730), connect
to the Power Grid via the CAN connector.
This increases control options over the
outputs and utilizes the Data Recorder.
Stand Alone
In stand alone mode, a separate pigtail
is offered that will connect to the MSD
CAN-BUS pigtail for the 12V and Ground
required to enable solid state relays.
A Loctite® Threadlocker 242® packet
is included to fasten the threaded screw
for the main power feed.
Apply a small amount of the Loctite
242. It will penetrate the thread grooves,
and bond within 10 minutes. Do not
apply too much Loctite, applying too
much can insulate the wire and cause
problems.
The medium strength bond can be
broken with hand tools, if necessary.
M S D
•
W W W . M S D P E R F O R M A N C E . C O M
PN 7764/77643
1-MSDView Software
1-USB Cable
1-Loctite 242 packet
Optional: Temperature Sensor PN 2934
WIRING FEATURES
MAIN HARNESS (16 PIN)
A
RED
B
RED
C-F
G
ORANGE
H
ORANGE
J
PINK
K
PINK
L
BROWN
M
WHITE
N,P
R
YELLOW
S
YELLOW
CAN CONNECTOR (6 PIN)
1
BLACK
2
YELLOW (SLV) 22GA
3
BLACK
4
RED
5
RED
6
•
( 9 1 5 )
12GA
OUTPUT 1
20GA
INPUT 1
NOT USED
20GA
INPUT 2
12GA
OUTPUT 2
12GA
OUTPUT 3
20GA
INPUT 3
20GA
TEMP SENSOR
REFERENCE (GROUND)
20GA
TEMP SENSOR SIGNAL
NOT USED
20GA
INPUT 4
12GA
OUTPUT 4
22GA
CAN LO
SHIELD
18GA
GROUND
22GA
CAN HI
18GA
POWER (12V)
NOT USED
8 5 7 - 5 2 0 0
•
F A X
( 9 1 5 )
1
8 5 7 - 3 3 4 4
