Summary of Contents for Shop+ T200sd
- Page 1 User Manual of digital Set Top Box T200sd T200sd Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
- Page 3 Important Safety Instructions Important Safety Instructions Warning: To reduce the risk of electric shock, do not remove the cover or back. There are no user-serviceable parts inside. Refer servicing to qualified personnel. Warning: To prevent fire or electric shock hazard, do not expose the unit to rain or moisture.
-
Page 4: Table Of Contents
Table of Contents Content Front and Rear Panel ....................1 Remote Control.......................2 1. Connections......................4 2. Quick Start Guide ....................5 2.1. First Time Installation ..................5 2.2. Auto Scan ......................6 2.3. Manual Scan ......................6 3. TV/Radio Operation.....................7 3.1. TV Operation .....................7 3.2. TV Channel List ....................8 3.3. -
Page 5: Front And Rear Panel
Front and Rear Panel Front panel 1.STANDBY INDICA TOR: Used to visually show power state of the set top box, the green LED will be light if turned on the set top box and the red LED will be light if the set top box entered standby mode. -
Page 6: Remote Control
Remote Control Remote Key Function: 1. MUTE:Used to turn the sound on or off. 2. NUMBER KEYS:Used to select channel numbers or input numbers in menus. 3. RECALL: Used to switch between the last two viewed channels. 4. INFO:Used to display information about the channel being viewed or further information about the program when in small EPG screen. - Page 7 Installing the Batteries Remove the battery cover from the Remote Control and put 2xAAA size batteries inside the compartment. The diagram inside the Battery Compartment shows the correct way to install the batteries. 1.Open the cover 2.Install batteries 3.Close the cover Using the Remote Control To use the Remote Control, point it towards the front of the Digital Set Top Box.
-
Page 8: Connections
Connections 1. Connections Caution: Make sure to check the voltage specification of the wall outlet is the same rating with the receiver. To prevent the risk of electric shock, do not open the cover or the back of the receiver. TV Aerial Coaxial Cable Coaxial Adapter... -
Page 9: Quick Start Guide
Quick Start Guide... -
Page 19: Main Menu
4.2. Channel Manager Channel Manager is used to rearrange channel sequence, remove channels, lock channels or set favorite channels. To rearrange channel sequence, press<Red Key> for selecting the desired channel. Use <Up> or <Down> keys to move the channel to where you want and press <Right Key>to confirm the new channel sequence. -
Page 21: Sleep T Imer
4.3.3. Auto Scan Timer Auto Scan Timer enables automatic search for new channels in both standby mode and operate mode. The default setting of auto scan timer in standby mode is “ON” (this timer only valid once a day for the first time to enter standby mode). The device will start automatic scan process one hour after it enters standby mode. -
Page 33: Troubleshooting
Troubleshooting If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section. -
Page 34: Technical Specifications
Technical Specifications USB JACK For file playback or software upgrade DC 5V Supply Voltage This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of life separately from your household waste.
