SPX LED WW
Luminaire
Part No.
Name
12610
SPX LED WW
*excluding shutter and lens tube
Accessories
Part No.
PCT1BE
AC Power Input Cable (39 inches/1 meter), powerCON TRUE1 without AC connector (bare end)
PCT1GP
AC Power Input Cable (39 inches/1 meter), powerCON TRUE1 with Stagepin Connector
PCT1GTL
AC Power Input Cable (39 inches/1 meter), powerCON TRUE1 with Twistlock Connector
PCT1GR
AC Power Input Cable (39 inches/1 meter), powerCON TRUE1 with Edison Connector
SC
Clamp, Get-a-Grip
82003
Safety cable, black, 1/8 x 30 w/hook
WARNINGS AND CAUTIONS
Note: Installation is entirely at your risk. Do not attempt installation unless you are suitably
qualified. Contact Strand Lighting or one of its authorized distributors for assistance.
When using electrical equipment, basic safety precautions should always be followed including the
following:
•
Do not use outdoors.
•
Do not mount near gas or electric heaters.
•
Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
•
The use of accessory equipment not recommended by
the manufacturer may cause an unsafe condition.
•
Do not use this equipment for other than intended use.
•
Refer service to qualified personnel.
INSTALLATION AND SETUP
Power Requirements
The SPX LED WW Luminaire requires standard AC power distribution from 100-240VAC, 50/60Hz.
Power is 295W max, and current varies depending on the voltage.
IMPORTANT AC POWER CONNECTION NOTES:
•
Use only approved cable types.
•
Do not overload circuits!
Connecting Power
Table 1 describes how to connect power to your SPX LED WW Luminaire.
SPX LED WW LUMINAIRE QUICK START GUIDE
Q
Thank you for purchasing a Strand Lighting SPX LED WW
Luminaire. We have designed this luminaire to provide you
with a superior fitting in performance, design, and
engineering. We are confident that it will perform to your
expectations for many years to come.
OVERVIEW
This document provides installation and operation instructions for the following
product(s):
Description
SPX LED WW - mains or DMX dimmable,
warm white profile luminaire engine
without lens tube
S
G
UICK
TART
UIDE
Weight*
6.2 kg
[13.67 lb]
Description
1
Dimensions*
(H x W x L)
414 x 327 x 380 mm
[16.29 in x 12.91 in x 14.72 in]
2000851
02.1704.0010
15 AUGUST 2018
Advertisement
Summary of Contents for Strand Lighting SPX LED WW
- Page 1 Refer service to qualified personnel. 2000851 INSTALLATION AND SETUP Power Requirements The SPX LED WW Luminaire requires standard AC power distribution from 100-240VAC, 50/60Hz. Power is 295W max, and current varies depending on the voltage. IMPORTANT AC POWER CONNECTION NOTES: •...
- Page 2 Connecting to the DMX512 Network Basic DMX512 installation consists of connecting multiple SPX LED WW Luminaires together (up to 30 luminaires) in "daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to the DMX connector on the first luminaire.
- Page 3 Step 4. Press [ESC] at any time to access Main Menu. Use with Mains Dimming In order for the SPX LED WW to dim between 0% and 100%, the connected dimmer must provide a minimum voltage to ensure the fixture is powered and ready to dim. The minimum required voltage level is shown in the tables below.
- Page 4 Front View Lens Tube Removal and Installation It is easy and quick to change to the lens tubes on a SPX LED WW Luminaire. Fixed beam and zoom lens tubes are interchangeable. CAUTION: Ensure the lens tube locking catch is fully engaged and safety cable is attached before putting fixture into use.
