SIZE OF MATTRESS
USE ONLY MATTRESS MEETING THE FOLLOWING SPECIFICATIONS ON UPPER AND LOWER BUNKS:
STANDARD TWIN: 74''-75'' LONG AND 37 ½'' - 38 ½'' WIDE
STANDARD FULL: 74''-75'' LONG AND 52 ½'' - 53 ½'' WIDE
ENSURE THICKNESS OF MATTRESS DOES NOT EXCEED 9'' ON UPPER OR LOWER BUNKS AND MATTRESS IS
AT LEAST 5'' BELOW UPPER EDGE OF GUARD RAILS.
OUR DEALERS OR MANUFACTURER
SKU#E840
Ver. 1.0 - 04/2016 - Pg 1/11
