Heat Alarm with Hush User Guide
240V AC 50Hz, 10mA, 9V battery back up, single and or multiple
station (18 units maximum), 57°C temperature rating
Model: OG30
ATTENTION: Please take a few minutes to thoroughly read this user guide which should be
saved for future reference and passed on to any subsequent owner.
09/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ongard OG30 and is the answer not in the manual?

Questions and answers

Related Manuals for Garland Ongard OG30

Summary of Contents for Garland Ongard OG30

  • Page 1 Heat Alarm with Hush User Guide 240V AC 50Hz, 10mA, 9V battery back up, single and or multiple station (18 units maximum), 57°C temperature rating Model: OG30 ATTENTION: Please take a few minutes to thoroughly read this user guide which should be saved for future reference and passed on to any subsequent owner.

  • Page 2: Table Of Contents

    15. Warranty & Contact Details Thank you for purchasing this heat alarm. It is an important part of your family’s home safety plan. You can trust Garland OnGard to provide the highest quality safety products. Please take a few minutes to thoroughly read this user guide, and save it for future reference.

  • Page 3: Product Features

    CO alarms, smoke alarms, or security systems. The heat alarms can be interconnected with up to 17 other Garland OnGard models as set out in Section 2 – Product Specifications. Do not connect to any other type or model of smoke, CO, or heat alarm.

  • Page 4: Product Specifications

    2. Product Specifications Model OG30 Electrical Rating 240V AC 50HZ, DC battery back up (9V battery) Interconnecting Smoke Up to any combination of 17 other alarm models. Compatible Models include: and Heat Alarms OG10, OG20, OG20LL, OG30. Temperature Rating 57°C Maximum Ambient 37.8°C Temperature Rating...

  • Page 5: Installation Instructions

    Garland OnGard advises that additional detection devices, installed within rooms, may be necessary.
  • Page 6 3. Recommended Locations • If a ceiling mounting location is not possible, the next logical location for mounting heat alarm is on the side wall. When mounting the alarm on the wall, use an inside wall with the top edge of the alarm at a minimum of 100mm and a maximum of 600mm below the ceiling.
  • Page 7 PEAK CEILING 3. Recommended Locations • When mounting the alarm on a sloping ceiling, it should not exceed 1500mm away from the apex. The spacing of additional alarms, if any, should be based on a horizontal distance measurement, not a measurement along the slope of the ceiling (see FIGURE 2B) FIGURE 2B 500mm NOT IN THIS AREA...

  • Page 8: Locations To Avoid

    3. Recommended Locations Mobile Home Installation: For Well Insulated Mobile Homes Install heat alarm as recommended on the previous pages. In mobile homes that are not well insulated extreme heat or cold can be transferred from the outside to the inside through poorly insulated walls and roof.
  • Page 9 • When alarms are interconnected, all interconnected units must be powered from a single circuit. • A maximum of 18 Garland OnGard AUS safety devices may be interconnected in a multiple station arrangement. The interconnect system should not exceed the interconnect limit of 12 smoke alarms...
  • Page 10 5. Wiring Instructions • The maximum wire run distance between the first and last unit in an interconnected system is 307 meters. Figure 3 illustrates interconnection wiring. Improper connection will result in damage to the alarm, failure to operate, or electrical shock hazard. •...

  • Page 11: Mounting Instructions

    6. Mounting Instructions CAUTION! THE BATTERY TAMPER BUTTON MUST BE HELD DOWN IN THE BATTERY COMPARTMENT BY THE BATTERY, TO ENSURE THE BATTERY DOOR WILL CLOSE, THE AC QUICK CONNECTOR WILL ATTACH TO THE ALARM, AND THE ALARM WILL ATTACH TO THE TRIM RING. NOTE: PLEASE ENSURE THAT BATTERY IS INSTALLED PRIOR TO MOUNTING OF HEAT ALARM.

  • Page 12: Operation And Test

    5. Now mount the heat alarm onto the trim ring. Rotate the heat alarm until the heat alarm snaps firmly into place. Switch on the AC power and the green AC power ‘ON’ indicator should be lit. The heat alarm is now operating on mains power. 7.
  • Page 13 7. Operation And Test TESTING THE HEAT ALARM Warning: test each heat alarm and smoke alarm to be sure that each is installed correctly and is operating properly. Stand at arm’s length from the heat alarm when testing. The alarm sounder is loud to alert you to an emergency and can be harmful to hearing.

  • Page 14: Alarm Nuisance And Hush

    8. Alarm Nuisance And HUSH Heat alarms respond only to heat. They do not detect smoke. If the alarm does sound, check for fires first. If a fire is discovered, get out of the house and call the fire brigade. If no fire is present, check to see if one of the reasons listed in Section 4 may have caused the alarm.

  • Page 15: Troubleshooting

    9. Troubleshooting PROBLEM SOLUTION Heat alarm does not 1. Check that AC power is turned on. sound when tested. 2. Turn off power. Remove heat alarm NOTE: Push and hold from mounting plate and: test button for at least a. check that connector plug is securely five (5) seconds while attached.

  • Page 16: Battery Replacement

    10. Battery Replacement Alarm Removal To replace the battery, remove the alarm from the trim ring by rotating the alarm in the direction of the “OFF” arrow on the cover (See section 6, Figure 4B). To disconnect the AC power harness, squeeze the locking arms on the sides of the Quick Connector while pulling the connector away from the bottom of the alarm (See Section 6, Figure 4A).

  • Page 17: Cleaning Your Alarm

    This alarm will not detect smoke, gases or flames. • Subject to applicable legal requirements in each State and Territory, Garland OnGard recommends that both ionisation and photoelectric smoke alarms be installed to help insure maximum detection of the various types of fires that can occur within the home. Ionisation sensing alarms may detect invisible fire particles (associated with fast flaming fires) sooner than photoelectric alarms.

  • Page 18: Good Safety Habits

    12. Limitations Of Heat Alarms of alcohol or drugs may also impair ones ability to hear the alarm. For maximum protection heat alarms should only be used as a supplement to smoke alarms. Smoke alarms should be installed in each sleeping area on every level of a home and be interconnected with each other and the heat alarms.

  • Page 19: What To Do When The Alarm Sounds

    14. What To Do When The Alarm Sounds • Leave immediately by your escape plan. Every second counts, so don’t waste time getting dressed or picking up valuables. • In leaving, don’t open any inside door without first feeling its surface.

  • Page 20: Warranty & Contact Details

    8. If the Customer makes a claim during the Warranty Period it will be handled as follows: In the case of Garland Products, where there is a defect in such Products, Garland will replace or repair the Products (at its discretion and cost).
  • Page 21 Any postage and packaging expenses required to return the product to Garland will be at your cost, but you may be entitled to a refund of those postage and packaging expenses where there is a major or minor problem with the products which entitles you to a repair or replacement.
  • Page 22 ABN 56 010 669 379 This warranty is provided by: Madison Technologies 149 Beaconsfield St, Silverwater NSW 2128 1800 66 99 99 www.garlandcables.com.au...
