AUTOMATIC JUICE MACHINES
®
OPERATION MANUAL
For Models JX15MC, JX15AC, JX15ACS, JX28MC,
JX28MCB, JX28AC, JX45AF, JX45AFR
Prior authorization must be obtained from Grindmaster-Cecilware™
GRINDMASTER-CECILWARE™
4003 Collins Lane
Louisville, KY 40245 USA
Phone:+1.502.425.4776
800.695.4500 (USA & Canada Only)
800.568.5715 (Technical Service Only)
Fax:
+1.502.425.4664
Email: ts@grindmaster.com
www.grindmaster.com
for all warranty claims.
Aug 2010
Part # NS40A Revision B
0810 Form # CW-302-02
© 2010 GRINDMASTER-CECILWARE
PRINTED IN USA
™
Advertisement
Table of Contents
Summary of Contents for Grindmaster Cecilware JX15MC
- Page 1 AUTOMATIC JUICE MACHINES ® OPERATION MANUAL For Models JX15MC, JX15AC, JX15ACS, JX28MC, JX28MCB, JX28AC, JX45AF, JX45AFR Prior authorization must be obtained from Grindmaster-Cecilware™ for all warranty claims. GRINDMASTER-CECILWARE™ Aug 2010 4003 Collins Lane Part # NS40A Revision B Louisville, KY 40245 USA 0810 Form # CW-302-02 Phone:+1.502.425.4776...
-
Page 2: Table Of Contents
Contents Model Specifications ....... General Information ....... Setup Procedures . -
Page 3: Model Specifications
/ Min Weight (H x W x D) 25 oz. - 45 oz. 33'' x 19.3'' x 17.7'' 111 lbs. JX15MC 6 Orange 120V, .55KW, 9A (.7 L - 1.3 L) (84 cm x 49 cm x 45 cm) (51 kg) 13 lbs. -
Page 4: General Information
For Indoor Use Only, using the machine in a location were it is exposed to rain can result in Electrical Shock or damage to the machine. JX15MC Unscrew the thumbscrew and connect the feeder tube. - Page 5 Setup Procedures JX28MC / JX28MCB Remove the pulp strainer and front cover. Connect the feeder tube and replace the pulp strainer and front cover. Connect the peel buckets and the drip tray. JX28AC Connect the auto feeder to the top of the machine and remove the pulp strainer and front cover.
-
Page 6: Warnings
Setup Procedures JX45AFR Follow the steps on page 5 for the JX45AF. Connect the caddy as illustrated. Before connecting the machine, please read the electrical information printed on the machine data plate. Make sure electrical supply matches the machines requirement. Plug the machine into a grounded electrical outlet. -
Page 7: Operation
Operation Depending on the model, add fruit to either the feeding tube or the auto feed carousel. TO BEGIN PROCESSING FRUIT: Press the switch on the upper right side of the machine (Position I). JX15ACS / JX45AF / JX45AFR: Once the machine has been started, press the faucet handle to activate the squeezing process. - Page 8 Cleaning Remove the pulp strainer. JX15MC / JX15AC / JX15ACS / JX28MC / JX28MCB / JX28AC: Empty the peel bucket. JX45AF / JX45AFR: Remove the down tubes. Remove the front cover. JX15MC / JX15AC / JX15ACS JX28MC / JX28MCB / JX28AC...
- Page 9 Cleaning JX28MC / JX28MCB / JX28AC JX45AF / JX45AFR Unscrew the five thumbscrews of the squeezing system parts. Remove the two squeezing drums, the two male parts and the knife by pulling outwards. (CAUTION! KNIFE IS SHARP) For models with auto feeder: First remove the metal basket, then the carousel by unscrewing the screw towards the right.
- Page 10 GRINDMASTER-CECILWARE™ 4003 Collins Lane Louisville, KY 40245 USA Phone: +1.502.425.4776 800.695.4500 (USA & Canada Only) 800.568.5715 (Technical Service Only) Fax: +1.502.425.4664 Email: ts@grindmaster.com www.grindmaster.com...
