CARAPP V100
Instruction Manual
AUTOPHIX TECH CO., LTD
www.autophix.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the CARAPP V100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Autophix CARAPP V100

  • Page 1 CARAPP V100 Instruction Manual AUTOPHIX TECH CO., LTD www.autophix.com...
  • Page 2 CARAPP V100...
  • Page 3 CARAPP V100 can be used to read fault codes, clear fault codes, display real-time information, test fuel consumption, analyze trip for OBDII supported car, and able to alarm unsafe driving behavior through voice prompt by Bluetooth and vehicle terminal communication in...
  • Page 4 => Main Features: With Bluetooth wireless communication technology and the operation experiences of phone touch in software, technology and usage is combined perfect in this product . The virtual instrument interface meets the owners desire for learning about the car; sensor parameters is simple to use while car is moving.

  • Page 6: How To Use

    => HOW TO USE After installing the software on the phone, you can click the CARAPP icon to enter the main menu, and slide the menu by your finger to select the function modules. If this is the first time, you can click on the "Setting"...
  • Page 8 Setting ① Bluetooth Enabled Reminder : Bluetooth feature turned on? It shows "YES" when the bluetooth has turned on, if not, it shows "No". ② Match Reminder : the phone OBDAPP Match ok? Click the right key to enter the match interface. Choose the matched hardware encoding for Bluetooth pairing.
  • Page 9 Note: when using this product, the onboard computer to pair.
  • Page 10 Click 'Bluetooth devices' search for Bluetooth devices.
  • Page 11 Will be shown paired Bluetooth devices.
  • Page 12 Click a Bluetooth device, enter the Bluetooth pairing request page. Enter the password, and click to confirm the pairing.
  • Page 13 ③ Connected to the ECU Reminder : The phone and OBDAPP to establish a connection it? "Query Bluetooth connection "window will pop up after clicking on the right key Choose the matched hardware encoding for Bluetooth pairing. It shows "YES" when the bluetooth has been paired, if not, it shows "No".
  • Page 14 For example, after you entered "120", it will be overspeed alarm voice prompt when the speed is over 120 kilometers per hour.
  • Page 15 ⑤ Water Temperature Alarm Reminder : when the Water Temperature over value alarm: "Reminder" window will pop up after clicking on the right key. You can input water temperature alarm value, and then click "OK". For example, after you entered "110", it will be water temperature alarm voice prompt when the speed is over 110 .
  • Page 16 then click "OK". For example, after you entered "3", it will be fatigue driving alarm voice prompt when the speed time is over 3 hours. ⑦ Alarm Settings Reminder : Turn on or turn off the alarm: click the "√ " to turn on, and click the choice box again to turn off in selection choice box on the right side.
  • Page 18 ⑧ Engine displacement Reminder : Engine displacement "Reminder" window will pop up after clicking on the right key. You can input engine capacity value, and then click "OK". For example, you entered "1.6", so the engine capacity value is 1.6. ⑨...
  • Page 19 Currency Reminder : Select the currency： After clicking the unit of currency button on the right side, it will pop up the currency selection window, so that you can select the monetary unit.
  • Page 20 Panel style Reminder : Setting panel style: Style Category : Black...
  • Page 21 Style Category : Red Click to select the real-time information on the instrument display style...

  • Page 22: Real-Time Information

    2. Real-Time Information Clicking the "Real-Time Information" module enter into the interface, you can slide the interface to select the single dial, two dials, six dials or six square dials to show the real-time vehicle information. If you click on the instrument panel more than 2 seconds, it will enter into the "Data stream selection"...
  • Page 24 The fingers continuous click on the instrument panel enters the stream selection page for more than 2 seconds.
  • Page 25 Do support the this data stream is showed in green font, and do not support the data stream is showed in white font. The instrument will display the real-time information of the data stream when you select data stream items which you want.
  • Page 26 For example, select the ‘Short Term Fuel Trim–Bank 1’...
  • Page 27 The Stream Selection Engine: Calculated LOAD Value Engine coolant Temperature Short Term Fuel Trim-Bank 1 Air Flow Rate from Mass Air Flow Sensor Absolute Throttle Position Fuel Level Input Evap System Vapor Pressure Barometric Pressure Control module voltage...
  • Page 29 Air-fuel: Fuel Rail Pressure(gauge) Intake Manifold Absolute Pressure Engine RPM Vehicle Speed Sensor Ignition Timing Advance for #1 Cylinder Intake Air Temperature...
  • Page 31 3. Vehicle in self-test Clicking the "vehicle in self-test" module to enter into the page.
  • Page 33 ① Readiness Test Click "Readinss Test" button to enter the page.
  • Page 34 The green reminder: finished test The red reminder: unfinished test The gray reminder: the vehicle does not support the test ② Fault Scan Clicking the "Fault Scan" button to get into the page. Yellow icon shows the determined fault, and the red one shows the current failure.
  • Page 35 Clicking "Remove" button to remove the fault code.
  • Page 36 ③ Failure Snapshot Clicking the "Fault Snapshot" button to enter the page. And then it shows the momentary information of vehicle you can hold current data by clicking "Save" button.
  • Page 38 ④ Historical Data Clicking the "Historical Data" button to enter the page.It shows all the data list which you saved before. You can click to select a data item list to enter into the "Diagnostic Report" page, and it will display the historical vehicle condition information.
  • Page 40 4. Fuel Consumption Test Clicking the "Fuel Consumption Test" button to enter the page. There are two pages in the module, you can use finger to slide interface for page changing.
  • Page 41 The functions in the first page as following: ① "Momentary Fuel Consumption in litres/ 100 km " : calculated the momentary value of fuel consumption per 100 km. ② "Vehicle Speed" : Displays the current speed. ③ "Revolving Speed" : Displays the current revolving Speed.
  • Page 43 The functions in the second page as following: ① "Momentary Fuel Consumption in litres/1 hour": calculated the momentary value of fuel consumption per hour. ② "Mileage": Displays the current miles. ③ "Fuel Consumption": display the fuel consumption values ④ "Average Fuel Consumption in litres/1 hour": calculated the average value of fuel consumption per hour.
  • Page 44 Note: The function of calculation starts from entering the fuel consumption test page until exit the module.
  • Page 45 5. Trip Analysis Clicking the "Trip Analysis" module to enter the page. There are three pages in the module, you can use finger to slide interface for page changing.
  • Page 46 The functions in the first page as following: ① "Drive Time": Displays the time of your driving. ② "Mileage": Displays the miles of your driving. ③ "Water Temperature": Displays the current water temperature ④ "Current Speed": Display the current speed of the vehicle ⑤...
  • Page 48 The functions in the second page as following: "Maximum Speed": Displays the maximum ① speed in the driving process ② "Overspeed Frequency: Displays the number of overspeed in the driving process. ③ "Overspeeding Time": Displays the cumulative overspeed time. ④ "Idle Time": Revolving speed is not zero, but accumulated from the zero state speed.
  • Page 50 Note: The function of calculation starts from entering the Trip Analysis page until exit the module. It will remind you to choose save or not. If choose hold the data, those data will be hold in the third page of Trip Analysis.
  • Page 51 6. Maintenance Records Clicking the "Maintenance Records" button to enter into the page.
  • Page 53 ① Add Maintenance Records Filling in vehicle maintenance, mileage and maintenance items, then click the "Add" button to save data.
  • Page 58 ② Check maintenance records Click to view the historical maintenance records.
  • Page 59 Click the “Delete” button to delete the maintenance records; Click the “Back” button to return to the previous page.
  • Page 60 => Specifications ·Specifications: 49mm X 27mm X 33mm ·Operating voltage: 8- 22V · Operating temperature: 0°C - 80°C (32-176 F°) · Storage temperature: -20°C - 70°C (-4 -158 F°) · Accessories: installation CD, product packaging , manual...
