- Page 1 Mini Turbo Charger O P E R A T I O N S M A N U A L...
- Page 2 Mini Turbo Charger...
-
Page 3: Table Of Contents
Introduction � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4 Mini Turbo Charger Overview � � � � � � � � � � � � � � � � � � � � � � � � 5 Charger Care Charging your Hearing Aids �... -
Page 4: Introduction
4 | Introduction The Mini Turbo Charger is designed to be a pocketable charging option for the lithium-ion rechargeable hearing aid. The charger works when plugged into a wall, or on-the-go with an on-board battery that will recharge a pair of hearing aids up to four times. -
Page 5: Mini Turbo Charger Overview | 5
Mini Turbo Charger Overview | 5 Features, Controls and Identification Micro USB Port Charging Ports Hearing Aid Charging LEDs (LEDs indicate state of charge for both the hearing aids and on-board battery) -
Page 6: Charger Care
6 | Charger Care Charging Your Hearing Aids Place your hearing aids on the Mini Turbo Charger with the earbud/earmold pointed out over the side of the charger, as shown above. Your hearing aids will turn off automatically and begin to charge. - Page 7 The LEDs will turn on for 10 seconds. Charging status of the Mini Turbo Charger on board battery can be observed with two quick taps to the charger while there are no hearing aids inserted.
-
Page 8: Turbo Charging
Charging the On-Board Mini Turbo Charger Battery The Mini Turbo Charger has a micro USB port for charging. The on-board battery is fully charged in under three hours. When fully charged, the on-board battery holds enough charge to fully charge a pair of hearing aids four times. -
Page 9: Mini Turbo Charger Care
– Do not expose to excess heat, i.e. do not store on a window sill or in a hot car. • Keep your Mini Turbo Charger in the sleeve while not in use or when being transported. * Nightly charging can occur in the charger. -
Page 10: Service And Repair
10 | Charger Care Service and Repair If, for any reason, your hearing aids and Mini Turbo Charger do not operate properly, do NOT attempt to fix them yourself. Not only are you likely to violate any applicable warranties or insurance, but you could easily cause further damage. -
Page 11: Troubleshooting | 11
Troubleshooting | 11 Troubleshooting Guide SYMPTOM POSSIBLE SOLUTIONS CAUSES To refresh LEDs, tap the top surface of the charger twice. The LEDs corresponding to the hearing aids Power save mode will illuminate to give status of charging for 10 seconds. They can No LED be refreshed again indicator... - Page 12 12 | Troubleshooting SYMPTOM POSSIBLE SOLUTIONS CAUSES Connect the micro USB to your charger and No LED plug it into the wall. indicator The on-board battery when hearing LEDs will turn on for a aid inserted Dead battery few seconds to indicate into the connection to the power charging port...
- Page 13 Troubleshooting | 13 SYMPTOM POSSIBLE SOLUTIONS CAUSES The Mini Turbo Charger on-board battery has died. Plug in your charger. If you do not Hearing aid have the cord with whistling in Dead battery you, push and hold the the charger hearing aid’s rocker...
-
Page 14: Regulatory Information
Hearing aids are available in multiple gain/ output levels appropriate to treat hearing losses ranging from mild-to-profound. The Mini Turbo Charger is used to charge the batteries in hearing aids that use rechargeable lithium-ion batteries. - Page 15 Regulatory Information | 15 We are required by regulations to provide the following warnings: WARNING: Use of the charger directly next to other electronic equipment should be avoided because it could result in improper performance. If such use is necessary, note as to whether your hearing aids and the other equipment are operating normally.
-
Page 16: Fcc Notice
16 | Regulatory Information The Mini Turbo Charger has been tested to, and has passed, the following emissions and immunity tests: • IEC 60601-1-2 radiated and conducted emissions requirements for a Group 1 Class B device as stated in CISPR 11. - Page 17 Consult Operations Manual INSTRUCTIONS FOR DISPOSAL OF OLD ELECTRONICS Starkey Hearing Technologies encourages, the EU requires, and your local community laws may require, that your hearing aids and charger be disposed of via your local electronics recycling/disposal process.
- Page 18 © 2018 Starkey Hearing Technologies. All Rights Reserved. 86191-056 12/18 BKLT3014-01-CF-SG-CN...
