Operating Frequency Range
Number of RF Inputs
Nominal Input & Output Impedance
Input Power Range per Channel
Selectable Output Power per Channel
In-Channel Inter-modulation Products
Channel-to-Channel Inter-modulation Products
All Harmonic Levels
(Exceeds FCC Part 74 & Part 15 Requirements)
Antenna VSWR Indicator Threshold
Operating Temperature Range
AC Line Operating Voltage & Frequency
Power Consumption
Dimensions
RF Connections
Additional Options Available
Radio Active Designs
21 East Union Avenue
East Rutherford, NJ 07073
Phone: 402-477-0695
www.RadioActiveRF.com
S
PECIFICATIONS
470-698 MHz
8
50 Ohms
25-250mW
50, 100, 250mW
Better than -35 dB (typical)
Better than -65 dB (typical)
Better than -40 dB
Greater than 2:1
-20 to +60°C
90-260 VAC 47-63 Hz
<125 Watts
19" W x 1U H x 12 ¾" D
BNC
Special Order
C
U
ONTACT
S
TX-8U
A
C
NTENNA
OMBINER
QUICK START GUIDE
TX-8U QSG Rev 10/17
