User Manual
Rev 1.0
Wireless control box USER MANUAL
model number: MOKWCO5103-S01 for Motion Wireless Cinema KIT
Features:
Opening/closing all the seats on a room simultaneously
Up to 9 rooms managed by a single remote
No limit room size
Easy pairing for new rooms
Optional pressure pads for presence sense
Auto-closing for empty seats
Emergency stop closing feature
Description:
The "Motion Wireless Cinema" KIT is thinked to give the possibility to the Cinema keeper to open or close entire
rooms with a single remote. This emprove the seats management when the room is empty, after a projection, to prepare
the room before a projection or eventually to permit a fast cleaning by opening all the seats together.
The basic Kit includes:
N.1 remote hand control
N.1 control box wireless
N.5 control box
N.5 hand control
N.1 power cable splitter
N.1 seat cable splitter
N.1 Power supply
Optional
N.5 Pressure pads
Functioning description:
The 5 seats are controlled by a single wireless control box that receives the wireless signal from the remote hand
control. If multiple Kits are installed, the wireless signal is automatically forwarded to the other kit up to complete
coverage of the room. Depending on the size of the room, some little movement delay can be detected between nearest
and farest Kits.
If the pressure pad is mounted on the seat, when a person is seated the control-box wireless control is hinibited and the
hand-control placed on the seat is enable. When the person stand up and leave the seat, after 5 seconds the seat
automatically start to close. For safety reason the user can stop this automatism by pressing any keys on the seat hand-
control; in this case the seat still blocked until a person will seats on or the cinema keeper will use the wireless remote
to open or close.
Motion S.P.A
- Wireless transmitter
- Wireless receiver
- Seats control box
- Seats hand control
- Seats sensor
Page 1 of 2
MOKWCO5103-S01
To be used with
[ Motion Wireless Cinema kit ]
(Motion code. MOKWCO2976-PB-S02 )
(Motion code. MOKWCO5103-S01 )
(Motion code. MOKWCO5104-S01 )
(Motion code. MOECCO2390-V01 )
(Motion code. MOECCO2389-V01 )
(Motion code. MOECCO5089 )
(Motion code. MOPS 2447 )
(Motion code. MOECCO5106 )
11/11/2016
Advertisement
Table of Contents
Related Manuals for Motion MOKWCO5103-S01
Summary of Contents for Motion MOKWCO5103-S01
- Page 1 Description: The “Motion Wireless Cinema” KIT is thinked to give the possibility to the Cinema keeper to open or close entire rooms with a single remote. This emprove the seats management when the room is empty, after a projection, to prepare the room before a projection or eventually to permit a fast cleaning by opening all the seats together.
- Page 2 Connector to the power splitter Fig. 1 The control box has to be powered exclusively by Motion power supply with Motion code. MOPS 2447. Connect all the cable before power the control box. Pairing new control boxes: To pair the control boxes of a new room with your remote, push the button on the front of the control box to pair, and then execute the following procedure on the remote: Press continuously the “Sync button”...
