Page 3: Chapter 1: Introduction
These instructions are published by Tele Draulic and are not subject to any guarantee. The instruc- tions may be removed or revised by Tele Draulic at any time and without further notice. Cor- rections and additions will be added to the latest version of the instructions. -
Page 4: About
1.2 About Before installing or operating the product, carefully read the instructions belonging to it. Hydra products are used together with different transmitters/receivers from the Hydra family. For your specific system see the technical documentation. Hydra mainly caters the Hydraulic market. The systems are not standardized but adjusted to the clients needs. -
Page 5: Chapter 2: Safety
Chapter 2: SAFETY 2.1 Safety To ensure safe operations this manual must be carefully read and understood before installing and operating the product. Installation must be made by authorized and educated personnel and according to the local laws and regulations. Failure to follow these instructions may cause death, serious injuries and material damages. -
Page 6: Functionality Test
Do not use damaged cables. No cables must hang loose. Avoid installing in areas affected by strong vibrations. The receiver withstands normal weather conditions but should be protected from extreme conditions. The receiver should also not be subjected to mechanical water pressure i.e. a pressure washer or similar adverse conditions. -
Page 7: Chapter 3: Product Description
Chapter 3: PRODUCT DESCRIPTION Note: The product pictures used in this chapter are for illustrative purposes only, actual product appearance might be slightly different. 3.1 Transmitter bottom view – all transmitters T24-81, T-24-82, T24-83 1. RFID antenna 5. Stop button 2. -
Page 8: Hy-T24-81
3.2 HY-T24-81 Transmitter top view 1. Handle bar 4. Display navigation buttons 7. Belt loops 2. Display function buttons 5. Paddle levers 1–6 3. Display 6. Buttons 1–6 Transmitter side views Left Right 1. Side button 1 4. Paddle levers 1–6 7. -
Page 9: Hy-T24-82
3.3 HY-T24-82 Transmitter top view 1. Handle bar 4. Display navigation buttons 7. Belt loops 2. Display function buttons 5. Joystick 1–2 3. Display 6. Buttons 1–6 Transmitter side views Left Right 1. Side button 1 4. Joysticks 1–2 7. -
Page 10: Hy-T24-83
3.4 HY-T24-83 Transmitter top view 1. Handle bar 4. Display navigation buttons 7. Belt loops 2. Display function buttons 5. Joysticks 1–3 3. Display 6. Buttons 1–6 Transmitter side views Left Right 1. Side button 1 4. Joysticks 1–3 7. Key switch 10. -
Page 11: Transmitter Display
3.5 Transmitter display The Menu system is controlled by the four buttons next to the display. 1. Back button 2. Select button 3. Battery LED 1 4. Status LED 5. Battery LED 2 6. Up 7. Down General navigation Main menu Up/Down Select menu item Select... - Page 12 LED indications The transmitter display area has 3 LEDs. LEDs 1 and 2 are for battery indication. Middle LED is for radio link and system information. Colour Action Indicates Battery LED 1 green lights Battery 1 level is good. lights Battery 1 level is low, must be charged.
-
Page 13: Leds On Receiver
3.6 LEDs on receiver The receiver has a button including seven LEDs showing the receiver status. 1. LEDs 1–5 2. DLEDs 1–2 3. Cap sensor button LED Colour Off On Flashes Indicates Radio link established No transmitter is registered ... - Page 14 Colour Action Indicates DLED1 green CANopen run LED (CAN interface 1) Flickering AutoBaud/LSS Single flash Stopped Blinking Pre-operational Operational DLED2 CANopen error LED (CAN interface 2) Single flash Warning limit reached Flickering AutoBaud/LSS Double flash Error Control Event Triple flash Sync Error Bus Off...
-
Page 15: Chapter 4: Technical Data
Chapter 4: TECHNICAL DATA SYSTEM SPECIFICATIONS Carrier frequency 2.4 GHz standard Frequency management Direct Sequence Spread Spectrum (DSSS) Field Strength Adaptation Feature Range (typical) 100m (328 ft), adjustable/depending on configuration Operating temperature -30 … + 70 °C (-30 .. +175 °F) Pairing Easy to pair without specialty tools or opening of boxes Bluetooth... -
Page 16: Chapter 5: Operation
Chapter 5: OPERATION Tele Draulic transmitters are intended to be used together with Tele Draulic waist belt, for better support and improved ergonomic while operating the transmitter. Adjust the belt around the waist, then hook the transmitter into the waist belt straps. -
Page 17: Start-Up Procedure
Note: Always hold the transmitter with the control panel towards you. The user must be able to read any text on the control panel and understand the symbols on it. Note: Transmitters not in use it must be switched off and stored in a secured storage space. 5.1 Start-up procedure Before operating the Hydra system the following procedure must be followed. -
Page 18: Maintenance
5.2 Maintenance Use the stop button to start and switch off the transmitter as often as possible. If error messages are shown, it is very important to find out what caused them. If the stop button is mechanically damaged, contact your representative for service imme- diately. -
Page 19: Chapter 6: Regulatory
Chapter 6: REGULATORY 6.1 CE marking This product is in compliance with the essential requirements of directive 1995/5/EC of the European Parliament and of the Council. Latest version of the EC Declaration of Conformity can be downloaded from the Tele Radio AB website. 6.2 FCC statement This device complies with part 15 of the FCC Rules. -
Page 20: Ic Statement
6.3 IC statement This product complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of device. -
Page 21: Fcc/Ic Label Placement
You will find the product label on the outside of the enclosure of the transmitter. 6.6 The radio module Each radio module is specifically designed to match a Tele Draulic product in terms of physical dimensions, connection points, voltage levels, signal interface etc. To use the radio modules in non Tele Draulic products is not permitted.
