snoWmobile Deluxe travel Cover
WARNING
When transporting your snowmobile on a trailer or
an open vehicle be sure to use and tighten all the
straps — the cover could blow off and cause injury
to others.
CAUTION
Failure to use and tighten all the straps when
transporting your snowmobile on a trailer or an open
vehicle can cause damage to your cover.
1. Cover any sharp points (such as a windshield corner)
with cloth or a sponge to avoid stressing your cover
when it is stretched tight across your snowmobile.
2. Find the label with arrows sewn in the hem of the
cover–this is the front of your cover. Now stretch the
cover down over your snowmobile making sure that
the front struts are covered. There are straps and
buckles for securing the front corners of the cover to
the struts of the sled. Find these straps and buckles
and run the male buckle around each strut and clip
it to the corresponding female buckle. Pull the strap
tight to secure it (Fig 1).
3. Locate the strap [A] in the middle of your cover
(Fig. 1). From where the strap attaches to the cover,
run the strap end with the male buckle under your
snowmobile and then back up to clip it into the female
buckle on the opposite side.
4. Run the forward strap [B] under your snowmobile
behind the ski struts and connect it into the buckle on
the opposite side (Fig. 1).
5. Run the rear strap [C] under the tail of your
snowmobile into the buckle on the opposite side.
F
E
A
D
B
Figure 1
6. There are three tension panels with webbing and
metal hooks for securing the cover for trailering. The
hooks can be attached to the sled or to the trailer.
a. Locate the front tension panel [D] with a webbing
strap and a metal hook (Fig 1). Attach the metal
C
hook to the front strut and tighten strap using the
ladder lock buckle.
b. Locate the other two tension panels [E] and [F] in
the seat area of your sled. Attach the metal hooks
and tighten the strap using the buckles. (These
straps can be removed and stored when the cover
is used just for storage).
7. Tighten ALL the straps as necessary for a tight fit on
your snowmobile.
Covering your snoWmobile When on
a trailer or on an open vehiCle
If you plan to cover your snowmobile while transporting
it on a trailer or open vehicle you must use and carefully
tighten all the provided straps to hold your cover down in
the winds created by high speed travel. When first using
your cover for highway travel we suggest you check your
cover after you have driven a short distance.
Cleaning
Clean your cover with a soft brush and some lukewarm
water. It may also be machine washed in COLD water.
DO NOT USE SOAP, as it may remove the protective
coatings added by the factory. Line dry or machine dry
on air or delicate.
storage
A handy storage sack is attached to the rear of your
cover. Be sure the cover is completely dry before you
store it in the sack for an extended period.
three year Warranty
This product is factory warranted for workmanship
and materials for three years after purchase. Trailering
without proper use of the provided tie-down straps will
invalidate the warranty.
©2007 Designed in the U.S.A.
71827 71837 71847
07cS59_002
