Tabler TTV-65MH Guiding Manual

GUIDING MANUAL
Thank you for your purchasing. Honestly wish you can enjoy the high-
quality VHrvice from TDEOHU6\VWHPV,QF. Please carefully read the Guiding
Manual BEFORE using the device.
CATALOG

(1) Packing List

(2) Instruction for Installation

(3) Connecting to A Computer
(4) FCC Statement
PACKING LIST
Touch Screen TV (with stand)
Guiding Manual
" "
Guiding Manual
Remote controller
Touch Screen USB Cable
" "
AAA Battery
Accessories
１
INSTRUCTION FOR INSTALLATION
Installing the screen
Notice:
Hinder heat radiation
• Do not cover or insert anything into the ventilation opening.
• .HHS FHUWDLQ VSDFH DURXQG WKH GHYLFH IRU KHDW UDGLDWLRQ
• 7KH 79 VKRXOG EH XVHG PRUH WKDQ FP IURP \RXU ERG\
• (QYLURQPHQW WHPSHUDWXUH
Wall
Avoidance for Setting:
• Please keep this device away from mechanical shake;
• Please avoid insects into this device;
• Please keep this device away from setting in front of air condition for preventing screen panel freezing;
• Please keep this device away from electromagnetic field against interference of electromagnetic wave.
Installing on stan Installing on stands
1. Disconnect all the cables with this device;
2. Place your touch screen TV carefully onto a flat stable desk with the backside up;
3. Put the left and right stands upon its bottom side, fasten the screws onto each stand and make sure it's stable. d right stands upon its bottom side, fasten the screws onto eac
INSTRUCTIONAL DIAGRAM
Wall Mounting
Please keep certain space for this device as the diagram.
5" – 400*00mm
Note: please use M6*12 screws for mounting on wall.
WR
２
