KodaCloud OAP30 Installation Manual

Dual band access point

Advertisement

Quick Links

OAP30 Dual Band
Access Point
Installation Guide
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OAP30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KodaCloud OAP30

  • Page 1 OAP30 Dual Band Access Point Installation Guide Installation Guide...
  • Page 2: Package Contents

    Package Contents...
  • Page 3: Step 1 - Connect The Access Point

    Step 1 - Connect the Access Point Connect one end of the Ethernet cable to the LAN1 Port (PoE) of the access point and the other end to the LAN + PoE (Power-over-Ethernet). Screw on the antennas (supplied separately) as shown in the following illustration. Connect the ground wire to the access point.
  • Page 4: Step 2 - Mount The Access Point

    Step 2 – Mount the Access Point Wall Mounting Determine where the AP is to be placed and mark location on the surface for the four mounting holes. You may adjust the position with a level. Use the appropriate drill bit to drill four 8 mm diameter and 37 mm depth holes in the markings and hammer the bolts into the openings.
  • Page 5 Place the lock and flat washer on the round head screws and drive the screws to attach mounting base to the back of the access point.
  • Page 6 Attach the device onto the wall by tightening the bolt’s flat washers and nuts to secure the mounting base to the mounting surface. Connect the ground wire (not shown) to a grounding point.
  • Page 7 Pole Mounting Place the lock and flat washer on the round head screws and drive the screws to attach the mounting base to the back of the access point.
  • Page 8 Determine which placement to be assembled. Drive the four round head screws to attach the pole mount bracket to the mounting base.
  • Page 9 Thread the open end of the pole strap through the two tabs on the pole mount bracket.
  • Page 10 Determine where the AP is to be fastened. Lock and tighten pole strap to secure pole mount bracket to the pole. Connect the ground wire (not shown) to a grounding point.
  • Page 11: Step 3 - Verify Connectivity

    Step 3 - Verify connectivity Verify that the OAP30 access point is connected to your network with either the KodaCloud website or the KodaCloud mobile device app. Check the Power LED to determine whether the access point is operating correctly. The access point is properly installed and connected to the KodaCloud management services when the LED turns solid green after a few minutes.
  • Page 12: Step 4 - Configure The Access Point

    Step 4 - Configure the Access Point Use your mobile device or the KodaCloud website. Website Sign into your account at http://KodaCloud.com and follow the instructions in the KodaCloud website to complete the process. Mobile Device Information about the mobile app is available at http://KodaCloud.com. The mobile device app includes instructions for completing the process.
  • Page 13: Tips And Troubleshooting

    Copyright and Trademark Copyright © 2016 KodaCloud, Inc. All rights reserved. The contents of this Installation Guide are the copyrighted and proprietary property of KodaCloud, Inc. Reproduction, distribution or modification without the express, written permission of KodaCloud, Inc.
  • Page 14: Legal Notice

    Open Source Code Certain KodaCloud products include open source software code subject to the GNU General Public License (GPL) and other Open Source Licenses. For more information, see: http://KodaCloud.com/opensource Legal Notice EXCEPT FOR ANY WRITTEN EXPRESS WARRANTY WE MAY SEPARATELY OFFER TO YOU, AND TO THE EXTENT PERMITTED BY LAW, THIS PRODUCT IS PROVIDED “AS IS”...
  • Page 15: Regulatory Compliance Information

    OAP30 Specifications and Safety Guidelines Specifications: Frequency Bands: Programmable for different country regulations Radio 1 – 2.400 to 2.484 GHz Radio 2 - 5.150 – 5.250 GHz, 5.725 – 5.850 GHz Standards: Radio 1 2.4G IEEE 802.11 b/g/n, Radio 2 5G IEEE 802.11 a/n/ac Input voltage and current: 54VDC @ 1.2A...
  • Page 16 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. There is no Country Code selection capability for USA Part # OAP30-UC. Professional installation instruction 1. Installation personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge.
  • Page 17 Use only the antennas which have been approved by the applicant. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC limit and is prohibited. 4. Installation procedure Please refer to user’s manual for the detail. 5.
  • Page 18 Industry Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 19 This equipment complies with IC radiation exposure limits set forth for an uncontrolled This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated environment. This equipment should be installed and operated with minimum distance 35 cm between the radiator &...
  • Page 20 DETACHABLE ANTENNA USAGE This radio transmitter (IC: 12659A-OAP30 / Model: OAP30) has been approved by ISED to operate with the antenna type listed below with maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
