Step 1
- Measure tub to Wall dimension
- Take Skirt (A) and Top Panel (B) and mark
dimension measured.
- Trace a line with a pencil and add tape along the
inside of the line
- Cut using a high speed blade from the acrylic side
of each piece to fit opening.
- Refer to Figure # 1.
B
A
Part Number
A
B
C
D
Wall
Extension Kit
Assembly Instructions
D
Description
Skirt
Top Panel
Sheet Metal Screw
Self tapping screws
Tub to wall
dimension
Figure # 1
C
Advertisement
Table of Contents
Summary of Contents for Safety Tubs Extension Kit
- Page 1 Extension Kit Assembly Instructions Part Number Description Skirt Top Panel Sheet Metal Screw Self tapping screws Step 1 Wall - Measure tub to Wall dimension - Take Skirt (A) and Top Panel (B) and mark dimension measured. - Trace a line with a pencil and add tape along the...
- Page 2 Extension Kit Assembly Instructions Step 2 - Once Skirt (A) and Top Panel (B) have been cut to desired size, Skirt (A) can be attached to the Tub by using Sheet Metal Screw (C) provided through Skirt (A) pre drilled holes.
- Page 3 Extension Kit Assembly Instructions Step 4 - In order to securely attach Skirt (A) and Top Panel (B) to the wall, wood stringers need to be added. - Refer to Figure # 4 Wood Stringers Figure # 4 Step 5...
