- Page 1 Warehouse Use Only Part # QUANTITY Part #: J2020S D069 Dimensions: 6” X 6” X 73” (Telescopic) D115 Weight: D119 G004 M13B A286-72S BG572...
-
Page 2: Product Info
PRODUCT INFO REQUIRED TOOLS Power Tool With 5/16” Drill Bit Part #: J2020S System: J2000 Material: Aluminum Fitment: Universal (Drilling Required) 1/2” Wrench Color: Silver 3/16” Allen Key Wrench Marker MARKER... - Page 3 PART # DESCRIPTION ITEM ITEM NOT DRAWN TO SCALE S052 DOUBLE SLIDER 2” BOLT TO BOLT S062 DOUBLE SLIDER 1 3/8” BOLT TO BOLT W008 5/16” X 3/4” WASHER B016 5/16” X 1 1/4” CARRIAGE BOLT B118 5/16” X 1 1/4” BUTTON HEAD ALLEN BOLT B065 5/16”...
-
Page 4: System Placement
ubbeR uaRds - Press the rubber bar guard into the channels of cross bars EZ-Velcro Strap Directions SYSTEM PLACEMENT MUST BE PLACED IN THIS ORDER FRONT S052 A286 W008 REAR N005 Do not tighten hardware... - Page 5 Align with interior plate to ensure bolt 4” alignment. *Mark with marker. *Remove van rack and use a 5/16” drill bit.
- Page 6 B016 W008 N005 Tighten all hardware 90° W008 B118 Repeat for all cross Bars N005 90° W008 S062 W008 B065 W008 N005 Installed onto front cross bar 90° Front Rear Velcro Strap Ladder Stopper Discover other commercial van equipment on our website.
