OPERATING INSTRUCTIONS
INTRODUCTION
The 4400 and 4800 Series mixers are the most truly automatic mixers available. Once
set up for an application, their proprietary circuitry functions automatically as if a trained
operator were at the controls, requiring little or no operator intervention. This automatic
operation, previously available only in the 4000 Series Automatic Mixer System is now
within the reach of smaller applications such as churches, meeting facilities, court-
rooms, council chambers, and any application requiring up to eight inputs.
The configuration of the system and setup of the options is described in the installation
instructions, Section 4 Group 20 Sub B. This document describes the operation of the
operator controls and indicators for the 4400 Series and 4800 Series Automatic Mixers,
all of which are located on the front panel.
The gating sensitivity of the gated inputs is independent of the front panel level control
setting, making level setup simple and straightforward. Set the Output control(s) at the
mid to
to the desired level. Finally, adjust the overall level with the Output controls.
4400 AND 4800 SERIES AUTOMATIC MIXERS
point (between12 o'clock and 3 o'clock position). Adjust each input individually
3
4
JAN 1993
MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS
MODELS 4400 AND 4800 SERIES
AUTOMATIC MIXERS
4
SECTION
20
C
1
GROUP
SUB
PAGE
Advertisement
Summary of Contents for IED 4400 Series
- Page 1 The configuration of the system and setup of the options is described in the installation instructions, Section 4 Group 20 Sub B. This document describes the operation of the operator controls and indicators for the 4400 Series and 4800 Series Automatic Mixers, all of which are located on the front panel.
- Page 2 MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS OPERATING INSTRUCTIONS ON/OFF SWITCH AND POWER LED Figure 1 - Front Panel Controls and Indicators Power switch and indicator LED The power On/Off switch is of the push-push type. When it is ‘Off’ it protrudes from the front panel.
-
Page 3: Auto/Manual Switch
OPERATING INSTRUCTIONS MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS AUTO/MANUAL SWITCH Figure 2 - Front Panel Controls and Indicators Auto/Manual Switch The Auto/Manual switch switches the mixer between automatic and manual operation. When the switch is in the Auto position, the gated inputs gate ‘On’ when an input signal is present, and gate ‘Off’... - Page 4 MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS OPERATING INSTRUCTIONS PHANTOM POWER ON/OFF Figure 3 - Front Panel Controls and Indicators Phantom Power On/Off Phantom power is the DC bias voltage required to make condenser microphones oper- ate. The phantom power On/Off switch controls the DC voltage which goes to each indi- vidual gated input.
- Page 5 OPERATING INSTRUCTIONS MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS OUTPUT GAIN CONTROLS Figure 4 - Front Panel Controls and Indicators Output Gain Controls The Output Gain Controls control the attenuation of the output level(s). The maximum level (full clockwise) depends upon the options and the setup. Refer to the product de- scription, Section 4, Group 20, Sub A and the installation instructions, Section 4, Group 20, Sub B for further details.
- Page 6 MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS OPERATING INSTRUCTIONS AUXILIARY INPUT GAIN CONTROLS Figure 5 - Front Panel Controls and Indicators Auxiliary Input gain Controls The Auxiliary Input gain controls control the level of the Auxiliary Input signal before it is mixed to the Main or Aux Output.
- Page 7 OPERATING INSTRUCTIONS MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS GATED INPUT GAIN CONTROLS Figure 6 - Front Panel Controls and Indicators ^F:\4_20C\4448FP-7.SFP^ The Input Gain Controls control the attenuation of the input level(s). The maximum level (full clockwise) depends upon the options and the setup. Refer to the product descrip- tion, Section 4, Group 20, Sub A and the installation instructions, Section 4, Group 20, Sub B for further details.
- Page 8 MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS OPERATING INSTRUCTIONS EQ CONTROLS Figure 7 - Front Panel Controls and Indicators EQ Controls The EQ controls adjust the cut or boost of the frequency response of each of the 3 bands of each input. The center frequency of the low band is 200 Hz, the mid band is 1 kHz, and the high band is 4 kHz.
- Page 9 OPERATING INSTRUCTIONS MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS GATE INPUT “ON” INDICATORS Figure 8 - Front Panel Controls And Indicators Input ‘On’ Indicators The input ‘On’ indicators are red LEDs mounted in the front panel, just to the right of the gated input gain controls.
- Page 10 MODELS 4400 AND 4800 SERIES AUTOMATIC MIXERS OPERATING INSTRUCTIONS This page left blank intentionally Innovative Electronic Designs, Inc. 9701 Taylorsville Road Louisville, Kentucky 40299 Phone: (502) 267-7436 Fax: (502) 267-9070 Internet: http://www.iedaudio.com SECTION GROUP PAGE JAN 1993 4400 AND 4800 SERIES AUTOMATIC MIXERS...
