Summary of Contents for StepTechnica HLSB38-IO32A
- Page 1 STD_HLSB38IO32A_V1.4E HLS（MKY38-IO32A） Intelligent 16IN/16OUT HLSB38-IO32A User's Manual...
- Page 2 5. This product is not designed for use in critical applications, such as life support systems. Contact us when considering such applications. 6. No part of this document may be copied or reproduced in any form or by any means without prior written permission from StepTechnica Co., Ltd.
- Page 3 HLSB38-IO32A User's Manual Revision history Date Version Content Note SEP 2018 1.4E Issued the first edition...
- Page 4 HLSB38-IO32A User's Manual Preface This manual describes HLSB38-IO32A, a general-purpose input and output board for HLS with MKY38-IO32A slave IC which is a kind of HLS family. Be sure to read "HLS Introduction Guide" in advance to use HLSB38-IO32A and understand this manual.
-
Page 5: Table Of Contents
HLSB38-IO32A User's Manual Table of contents 1 Outline .............................................1-1 2 Specifications........................................1-1 3 Block diagram ........................................1-2 4 Functions ..........................................1-3 4.1 MKY38-IO32A（HLS slave device） ..............................1-3 4.2 HLS communications ....................................1-3 4.3 General-purpose inputs ..................................1-3 4.4 General-purpose outputs ..................................1-4 5 External view .........................................1-4 6 Switches ..........................................1-5 6.1 HLS SA (Satellite Address), communication rate setting switch（SW2） ................1-5 6.2 HLS communication mode （full-duplex, half-duplex）setting switches（SW3, SW4）... - Page 6 HLSB38-IO32A User's Manual Figures Fig. 3-1 HLSB38-IO32A block diagram .................................1-2 Fig. 4-1 Input equivalent circuit ..................................1-3 Fig. 4-2 Output equivalent circuit ..................................1-4 Fig. 5-1 External view ......................................1-4 Fig. 6-1 HLS SA, communication rate setting switch（SW2） ......................1-5 Fig. 6-2 HLS communication mode setting switches（SW3, SW4） ....................1-6 Fig. 6-3 General-purpose input digital filtering setting switch（SW1） ..................1-6 Fig.
-
Page 7: Outline
This product is powered from 24V external power supply, which is isolated by DC/DC converter on the board and operates with 3.3V inside circuit. This board fits on DIN rail with cover equipped. Type name of the product with case is 'HLSB38-IO32A-C'. 2 Specifications The specifications of HLSB38-IO32A is shown in Table 2-1. -
Page 8: Block Diagram
DC/ DC converter isolates DC24V external power supply into Internal circuit power supply DC3.3V internal operating voltage. Consumption current 150mA or lower （DC24V） 3 Block diagram The block diagram of HLSB38-IO32A is shown in Fig. 3-1. Fig. 3-1 Block diagram of HLSB38-IO32A... -
Page 9: Functions
Termination resistor (100 Ω ) can be set enable / disable with DIP switches (SW5, 6). 4.3 General-purpose inputs HLSB38-IO32A supports 16 general-purpose input signals. Each input signals are isolated by photocoupler and connected to HLS slave IC （MKY38-IO32A）. The input method is current source type, which can be connected to switches and sensors. -
Page 10: General-Purpose Outputs
HLSB38-IO32A User's Manual 4.4 General-purpose outputs HLSB38-IO32A supports 16 general-purpose output signals. Each input signals are isolated by photocoupler and the board can be driven with high current. The output method is current sink type, which can be driven with maximum of 300V, 100mA and connected to motors, relays, LEDs, switches, and sensors. -
Page 11: Switches
OFF. Fig. 6-1 HLS SA, communication rate setting switch（SW2） SA （Satellite Address） of HLSB38-IO32A is set in SW2-1 to SW2-6. Communication rate （BPS） is set in SW2-7 and SW2-8, are shown in Table 6-1. Table 6-1 HLS communication rate settings State of SW2-7（BPS0）... -
Page 12: Fig. 6-2 Hls Communication Mode Setting Switches（Sw3, Sw4
HLSB38-IO32A User's Manual 6.2 HLS communication mode（full-duplex, half-duplex） setting switches（SW3, SW4） HLS communication mode of HLSB38-IO32A can be set in SW3 and SW4. Be sure to set SW3 and SW4 same as each other. Factory setting is full-duplex mode（2-3）.（Same as Fig. 6-2）... -
Page 13: Hls Termination Setting Switches（Sw5, Sw6
・HLS communication connector（CN1, CN2） ・General-purpose input connector（CN4） ・General-purpose output connector（CN5） 8.1 Power supply connector（CN3） CN3 is a power supply connector of HLSB38-IO32A, which to input DC24V. Connector pin assignment is shown in Table 8-1. Connector manufacturer ： Phoenix Contact Connector part number ： SPTA1/4-3,5 Table 8-1 Power supply connector（CN3）... -
Page 14: Table 8-3 General-Purpose Input Connector Pin Assignment（Cn4
HLSB38-IO32A User's Manual 8.2 HLS communication connectors（CN1, CN2） CN1, CN2 are HLS communication connectors. Connector pin assignment is shown in Table 8-2. CN1 and CN2 are the same pin assignment. Connector manufacturer ： Hirose Connector part number ： TM11R-3C-88（50） RJ-45 type Table 8-2 HLS connector pin assignment（CN1, CN2）... -
Page 15: External Dimensions
HLSB38-IO32A User's Manual 9 External dimensions External dimentions of board is shown in Fig. 9-1 and external dimensions with case which supports DIN rail mounting is shown in Fig. 9-2. Fig. 9-1 External dimensions of board Fig. 9-2 External dimensions with case... - Page 16 ■ Developed and manufactured by StepTechnica Co., Ltd. 757-3, Shimofujisawa, Iruma, Saitama http://www.steptechnica.com/en/index.html info@steptechnica.com HLS（MKY38-IO32A） Intelligent 16IN/16OUT HLSB38-IO32A User's Manual Document No.：STD_HLSB38IO32A_V1.4E Issued：September 2018...
