Antik GX-5000 Operation Manual

Digital contents processing platform. digital headend system
Hide thumbs Also See for GX-5000:
Table of Contents

Advertisement

Quick Links

Download this manual
数字
前端系
Digital Headend System
Solution . System .
Service
GX-5000
Digital Contents Processing Platform
GX-5000
Operation Guide
Version 1.0
www.antiktech.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GX-5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Antik GX-5000

Summary of Contents for Antik GX-5000

  • Page 1 数字 前端系 Digital Headend System Solution . System . Service GX-5000 Digital Contents Processing Platform GX-5000 Operation Guide Version 1.0 www.antiktech.com...
  • Page 2 Service About this Guide Thank you for purchasing the digital TV headend equipment from ANTIK . This operation guide is intended for technical personnel who use Digital Contents Processing Platform, GX-5000, describes the operation of the equipment. In the following table, we provide the document release history.
  • Page 3 Products and Repairs returned by Purchaser shall be repaired by ANTIK using new or refurbished parts and shall be returned to Purchaser by ANTIK , shipping prepaid by ANTIK. This warranty shall immediately become null and void if, in ANTIK's sole judgment, the Product has been...
  • Page 4 All customer-returned units must be shipped to ANTIK freight prepaid, in the original carton or equivalent. ANTIK is not responsible for damage in transit. All repairs will require return of the entire equipment to ANTIK. No individual modules will be accepted for repair under this contract.

  • Page 5: Table Of Contents

    数字 前端系 Digital Headend System Solution . System . Service Table of Contents 1. SAFETY PROTECTION..........................1 2. INTRODUCTION.............................2 2.1. Appearance............................2 2.2. Function Cards introduction........................3 3. LCD Menu.................................8 3.1. Main Menu............................. 10 3.2. Network..............................10 3.3. Misc................................ 11 3.4.

  • Page 6: Safety Protection

    Service SAFETY PROTECTION This User Guide is written for operators/users of the GX-5000 to assist in installation and operation. Please read this User Guide carefully before installation and use of the device. This equipment is provided with a protective earth grounding incorporated in the power cord. The main plug shall only be inserted in a socket outlet provided with a protective earth contact.

  • Page 7: Introduction

    Appearance GX-5000 appearance is shown as Fig.2-1 GX-5000 Appearance. GX-5000 Fig.2-1 GX-5000 Appearance LED Indicators There are 11 LED indicators on GX-5000 front panel which refer to Fig.2-2, including, 1. Power 2. Warning 3. Alarm 4. Module 1-6 Status 5. User-defined A/B (not available in this version, and LED A is defined for P01MS) Fig.2-2 LED Indicators...

  • Page 8: Function Cards Introduction

    There are six keys on front panel, UP, Down, Left, Right, Enter and Exit. User can check and setup LCD Menu with them. USB is just for firmware update. USB is one of GX-5000 three (USB, Telnet and Web) different types of firmware update methods. User need to put firmware into USB key root folder, update it through upgrade menu of LCD.
  • Page 9 数字 前端系 Digital Headend System Solution . System . Service 15Gbps data processing capability Compliant with ISO13818 & EN300 468 MEPG/H.264 TS re-Multiplexing & Scrambling Local & Remote CAS multi-crypt DVB CAS & BISS PID filtering, remapping, pass through & mapping Insert &...
  • Page 10 数字 前端系 Digital Headend System Solution . System . Service ISI ID: 1 ~ 255 user configurable 2. 2. 4. D01T2（4 x DVB-C/T/T2 Demodulator Module） 4 x F type Female, 75Ω Full compliant for DVB-T2 v1.3 Input Frequency, 48 ~ 860 MHz(DVB-C), 104 ~ 862 MHz(DVB-T/T2) Input Level, -15~ 15dBm(DVB-C), -70 ~ -20dBm(QEF, DVB-T/T2) Symbol Rate, 1 ~ 7MSps（ITU J.83 Annex A DVB-C）...
  • Page 11 数字 前端系 Digital Headend System Solution . System . Service BER < 10E-9 Spurious rejection > 55dB Output return loss -10dB 2. 2. 7. C01MOD（8 x QAM/4 x COFDM Modulator Module） 2 x F type Female, 75Ω（1 x main output，1 x -20dB monitor output） Support QAM/COFDM Modulation Mode(cannot work at the same time) 2 groups of 4 adjacent channel carriers QAM RF output, 2 groups of 2 adjacent channel carries COFDM RF output...
  • Page 12 数字 前端系 Digital Headend System Solution . System . Service 2. 2. 9. P01DA（2 x DS3 Input/2 x DS3 Output/1 x ASI Adaptor Module） 5 x BNC Female, 75Ω Standard: DVB-ASI, EN50083-9 / ITU-T G.703 Frame Structure: ITU-T G.752 / ITU-T G.804 ASI Input or Output can be switched Bit rate: 44.736Mbps 2.

  • Page 13: Lcd Menu

    数字 前端系 Digital Headend System Solution . System . Service 3. LCD Menu There is a LCD Menu for users to configure main frame and front interfaces. User can press enter key to start to setup the unit. The LCD menu overview showed as below: www.antiktech.com...
  • Page 14 数字 前端系 Digital Headend System Solution . System . Service www.antiktech.com...

  • Page 15: Main Menu

    Solution . System . Service 3.1. Main Menu The LCD will show GX-5000 and management IP address when it boot up. User can press any key of front panel to enter Main menu. Main menu includes 3 submenus, Network, Misc and System. GX-5000 3.2.

  • Page 16: Misc

    数字 前端系 Digital Headend System Solution . System . Service 3.3. Misc This menu includes several unit’s status, Date, Time, Temperature, Fan status, Power supply, Error Operate and Device label. User can setup Date and Time to display via front panel. Temperature is unit inside temperature. Fan status will show error if any fan does not work.

  • Page 17: System

    数字 前端系 Digital Headend System Solution . System . Service 3.4. System System menu includes these sub-menus, S/N, Version, Reset Module, Switch USB-RS, Factory Settings and Machine Settings. S/N is the identification of the unit and it is an unique series number for each unit. It helps to verify if the unit comes original or not.
  • Page 18 数字 前端系 Digital Headend System Solution . System . Service www.antiktech.com...

  • Page 19: Web Interface

    Solution . System . Service 4. Web Interface Web browser is the main management interface of GX-5000. User can check the unit working status, setup and reset it etc. The suggestion browsers are Chome, IE version 11 or higher. 4.1. System Status This is the page for main frame working status.
  • Page 20 数字 前端系 Digital Headend System Solution . System . Service Tuner Status Tuner configure Menu Name Description To configure the local oscillator frequency according to the right satellite, LNB LO Frequency its range is from 1000 to 26,500MHz. To configure the satellite down link frequency according to the right Satellite Frequency satellite, its range is from 1000 to 26,500MHz.
  • Page 21 数字 前端系 Digital Headend System Solution . System . Service 45,000KBaud. To select the correct LNB voltage output from the F-connector, user can LNB Voltage choose between Off, 13V and 18V. To activate the LNB 22KHz control signal to the LNB, user can select LNB 22KHz between On and Off.

  • Page 22: D02S2（4 X Dvb-S/S2 Demodulator Module, Support Input Stream Indentifier

    数字 前端系 Digital Headend System Solution . System . Service 4.2.3. D02S2 （ 4 x DVB-S/S2 Demodulator Module, Support Input Stream Indentifier） Please refer 4.2.2. 4.2.4. D01T2（4 x DVB-C/T/T2 Demodulator Module） The D01T2 is a 4 independent channels DVB-T2/T/C demodulator module, it supports 3 different demodulation modes, DVB-T2, DVB-T and DVB-C.
  • Page 23 数字 前端系 Digital Headend System Solution . System . Service Default demodulation mode Demodulation mode www.antiktech.com...

  • Page 24: P01Ci（4 X Ci De-Encryption Module

    数字 前端系 Digital Headend System Solution . System . Service Default demodulation bandwidth Menu Name Description Demodulation mode option Signal Type Receiving signal frequency option Frequency Bandwidth option Bandwidth PLP option (Just for stream which includes PLP ID) Multi PLP ID 4.2.5.
  • Page 25 数字 前端系 Digital Headend System Solution . System . Service Default status Menu Name Description Transport stream which input and output the CI slot TS IN/TS OUT CAM name or No Module which mean CAM not installed or recognized Slot Transport stream used for CI slot, it will show which module and Source source are available...
  • Page 26 数字 前端系 Digital Headend System Solution . System . Service Step2: select the transport stream which will be used for CI slot; Step3: Select services which need to decrypting and click apply. www.antiktech.com...

  • Page 27: C01Qam（8 X Qam Modulator Module

    数字 前端系 Digital Headend System Solution . System . Service 4.2.6. C01QAM（8 x QAM Modulator Module） The C01QAM is a 8 channels, 2 groups 4 adjacent frequencies, QAM modulator. Each channel has switch for enable or disable the RF output. And each channel also can be configured with independent transport stream. Status page will show each channels working status.
  • Page 28 数字 前端系 Digital Headend System Solution . System . Service Default source options Below is the procedure for setup modulator: Step1: select module or M/B which will be used for modulator Step2: select the specific transport stream for modulator www.antiktech.com...
  • Page 29 数字 前端系 Digital Headend System Solution . System . Service Step3: setup RF Level for output: Step4: to setup modulation/RF switch as ON www.antiktech.com...
  • Page 30 数字 前端系 Digital Headend System Solution . System . Service Step4: to setup constellation Step5: to setup I/Q Inversion www.antiktech.com...
  • Page 31 数字 前端系 Digital Headend System Solution . System . Service Step6: to setup band width: Step7: to enter Frequency and Symbol rate, this just for Modulator-1 and Modulator-5, the reset will increased following up according to bandwidth. www.antiktech.com...

  • Page 32: C01Mod（8 X Qam/4 X Cofdm Modulator Module

    数字 前端系 Digital Headend System Solution . System . Service Step8: to setup NIT filter, it will pass NIT if the option is enable, Disable will not pass through NIT. NIT PID is for customer defined PID which instead NIT pass through. Step9: after all setups, need to click Apply to save and enable all of them.

  • Page 33: C01Asi（5 X Asi Input/Output Module

    数字 前端系 Digital Headend System Solution . System . Service 4.2.8. C01ASI（5 x ASI Input/Output Module） This is a 5 BNC for ASI input and output software option card. User can define the input and output via Web interface configuration. And there is additional option for demodulating T2MI. This Status page will show bitrate input or output from each of 5 BNC.
  • Page 34 数字 前端系 Digital Headend System Solution . System . Service ASI output-1 ASI output-2 The ASI page is for configure BNC, input or output. There are two options for each BNC, ASI In or ASI Out. www.antiktech.com...
  • Page 35 数字 前端系 Digital Headend System Solution . System . Service BNC configure For special using, user can set this card mode as T2MI mode, as picture showed below. After setup as T2MI mode, BNC 5 will fixed as ASI input for T2MI function. Mode option T2MI page will show up when the card set as T2MI mode.

  • Page 36: P01Da（2 X Ds3 Input/2 X Ds3 Output/1 X Asi Adaptor Module

    数字 前端系 Digital Headend System Solution . System . Service T2MI configure 4.2.9. P01DA（2 x DS3 Input/2 x DS3 Output/1 x ASI Adaptor Module） Under development!!! 4.2.10. D01PA（2 x Channels Multi-format Signal SD/HD Decoder Module） This the decoder card is two channels decoders with HDMI and CVBS interfaces. User can select stream from source menu and to configure the decoding on Decoder menu.
  • Page 37 数字 前端系 Digital Headend System Solution . System . Service Decoder Status Below is the procedure for setup Decoder: Step1: select module or M/B which will be used for decoder and select stream from the selected module or M/B; Decoder source-1 Step2: select which service will be used for decoding, user will see output from HDMI or CVBS after this step.Please refer Status page if there is no output.
  • Page 38 数字 前端系 Digital Headend System Solution . System . Service Decoder Step3: user can adjust out video resolution if user want to see the particular resolution. Resolution configure Step4: user can adjust out Aspect Ratio too if user want to see the particular aspect ratio. www.antiktech.com...
  • Page 39 数字 前端系 Digital Headend System Solution . System . Service Aspect Ratio Step5: user can use default setting under most situation, and configure it as required. CVBS PAL Step6: Audio mode include Auto, Stereo, Mono, Left and right. User can configure it as required. www.antiktech.com...

  • Page 40: P01Ec（4 X Hdmi Mpeg-2/H.264 Transcoder/Encoder Module

    P01EC（4 x HDMI MPEG-2/H.264 Transcoder/Encoder Module） This the HDMI encoder card of GX-5000. It supports 4 channels HDMI encoder, and it can be used as a transcoder too. The 4 encoders are independent hardware, the options for each encoder will not effect others.
  • Page 41 数字 前端系 Digital Headend System Solution . System . Service Quick setup example: Step1: select on encoder page from encoder 1 to 4. Step2: configure the card operation mode, H264 or MPEG2 encoding or MPEG2 To H264 transcoding. Encoder Bit Rate is for encoding output bit rate, Video + Audio + Null packets. Step3: user can select Video Rate control from CBR and VBR.
  • Page 42 数字 前端系 Digital Headend System Solution . System . Service Step4: user can setup video bit rate, video max bit rate and video min bit rate. The difference between Max and Min is the range for video encoding or transcoding. Aspect Ratio will be 16:9 or 4:3. Step5: GOP size option will be enabled while the GOP Adaptive option is OFF.
  • Page 43 数字 前端系 Digital Headend System Solution . System . Service Step6: The Output Horizontal and Vertical can be enabled when the Output video format is Manual Settings. If it is Auto Settings, video output format will be same as input. The Input Format adaptive is for recognize input video format automatically.
  • Page 44 数字 前端系 Digital Headend System Solution . System . Service Audio Format: set the audio compression format MPEG-1 Layer II, MPEG-2 AAC LC, MPEG-4 AAC LC, MPEG-2 AAC HE-V1, MPEG-4 AAC HE-V1, MPEG-2 AAC HE-V2, MPEG-4 AAC HE-V2 Audio Bit Rate: Set the audio bitrate, available options: 64k bps /96k bps /112k bps /128k bps /160k bps /192k bps /224k bps /256k bps /320k bps /384k bps Audio Level: Set the gain of output volume from -7dB to +12dB.
  • Page 45 数字 前端系 Digital Headend System Solution . System . Service on the page Source/Enc Mux. After setup source, user needs to select service and audio on the Trans/Encoder page. The program source could be select from each of four transcoder sources. The rest options please refer to Encoder options process. www.antiktech.com...

  • Page 46: Ts Over Ip

    数字 前端系 Digital Headend System Solution . System . Service 4.3. TS over IP There are two TS over IP ports on the main chassis. These two ports are duplex mode, can be used as input and output at same time. TS over IP input: Before users to setup the IP input channels, they need to Click Add button to add channels for configuring.
  • Page 47 数字 前端系 Digital Headend System Solution . System . Service TS over IP output: It is same as TS over IP input, there is a Quick setup. The process is same as input too. Menu Name Options Add TS over IP channels Apply all checked rows settings Apply checked Delete all checked rows settings...

  • Page 48: System

    数字 前端系 Digital Headend System Solution . System . Service TS/IP Local This menu is to setup TS over IP ports physical IP address, Network mask and Gateway IP address. 4.4. System The System page is for configuring management IP, Device label and Web login ID and Password etc. www.antiktech.com...
  • Page 49 数字 前端系 Digital Headend System Solution . System . Service Menu Name Options Management IP address IP Address MAC address of ethernet MAC Address Network mask of management Network Mask Gateway of management Gateway IP Address Device label setup option Device label Serial number of the main chassis Serial Number...

  • Page 50: Remux

    Digital Headend System Solution . System . Service Main chassis firmware versions Version Sub-module reboot options, user can specific module to reboot Reboot Module independently Default Parameter is for facotory default Save Parameter is for saving configurations as a file Parameter Upload and Reset is for uploading configure file and reset the unit configure as saved file...
  • Page 51 数字 前端系 Digital Headend System Solution . System . Service Quick setup example: Step 1: select sources will be used as remux source, click Apply Src to sync sources before doing remux; Step 2: move mouse cursor to the channels which under modules and click right button of mouse, Capture button will show up;...
  • Page 52 Digital Headend System Solution . System . Service Step 3: click Capture button and all programs information will show up under channel menu; Step 4: move mouse to program which will be used for remux and drag the channel to one of the 16 remux channel, or select more programs and drag to remux menu at once;...
  • Page 53 Digital Headend System Solution . System . Service Step 5: click m1 edit button to setup remux channel; Step 6: move mouse to program of remux and click right button of mouse to edit program; www.antiktech.com...
  • Page 54 Digital Headend System Solution . System . Service Step 7: the last step is to enable remux channels by click Apply All or Apply Selected button; www.antiktech.com...
