Introduction
The USB 2.0 to VGA allows you to connect an
additional display to your desktop or notebook
PC and use it as an extended desktop or as an
additional larger/different display for your main
screen.
Features and Benefits
•
Compliant with USB specification, Rev.2.0
•
Supports suspend and wake-up modes
•
Functionality: primary, extended and mirror
•
Resolution: up to 1680 x1050 @ 32-bit color
Lot Number Sticker
For future product return or exchange, this lot
number is required. Please keep it for your
reference.
Lot Number
04-0473J
USB 2.0 to VGA
Installation Guide
Part Number
1
Advertisement
Table of Contents
Summary of Contents for SIIG USB USB 2.0 to VGA
- Page 1 USB 2.0 to VGA Installation Guide Introduction The USB 2.0 to VGA allows you to connect an additional display to your desktop or notebook PC and use it as an extended desktop or as an additional larger/different display for your main screen.
-
Page 2: Package Contents
64-bit) / 7 (32-/64-bit) / Vista (32-/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32- /64-bit) / Server 2008 R2 Package Contents • USB 2.0 to VGA • Driver CD • Installation guide Layout VGA port USB port Figure 1: USB 2.0 to VGA... -
Page 3: Installation
Installation Make sure the proper version driver for your graphics card is installed, the USB 2.0 to VGA is not designed to work with Windows' Standard VGA Graphics Adapter driver. Note: DO NOT plug the USB 2.0 to VGA adapter into your computer's USB port until you are instructed to do so. -
Page 4: To Verify Installation
While Windows is restarting, connect your second monitor to the USB 2.0 to VGA and turn it on. When Windows resumes, plug the USB 2.0 to VGA into the computer, and it's ready for use. To Verify Installation From the desktop, right click This PC, Computer or My Computer, then click Manage. -
Page 5: Display Utility
Display Utility After successful driver installation, the icon will appear in the taskbar by the system clock. This utility allows you to change the viewing modes, screen resolution, screen rotation, and physical arrangement of your monitors. Access the utility by right clicking the icon. Note that the utility icon may be hiddden in the Windows System Tray. - Page 6 Duplicate Desktop: Displays the same image on both monitors (Mirror mode) • Make This My Main Display: Sets the connected display of the USB 2.0 to VGA as the main display • Disconnect This Display: Disables the connected display of the USB 2.0 to VGA •...
- Page 7 Figure 3 • Screen Resolution: Choose from advanced options such as display resolution, display orientation and multiple display modes (Mirror / Extend / Primary), see Figure 4 Figure 4 • Select a Language: Choose the preferred language from the list •...
-
Page 8: Frequently Asked Questions
Q2: There are lines running up and down my screen or the screen is distorted A2: This is due to a low or unsupported refresh rate. Make sure you select the USB 2.0 to VGA and not set the refresh rate higher than what your monitor can support. - Page 9 Blank page...
- Page 10 Blank page...
-
Page 11: Technical Support And Warranty
Technical Support and Warranty QUESTIONS? SIIG’ s Online Support has answers! Simply visit our web site at www.siig.com and click Support. Our online support database is updated daily with new drivers and solutions. Answers to your questions could be just a few clicks away. You can also submit questions online and a technical support analyst will promptly respond. - Page 12 Fremont, CA 94538-3152, USA Phone: 510-657-8688 USB 2.0 to VGA is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. All other names used in this publication are for identification only and may be trademarks of their respective owners.
