SG10-115RG VAC UNIT
BLACK
RED
GREEN
WHITE
(NEUTRAL)
X2
GREEN
BLACK
(LABELED 'GREEN')
info@triliteinc.com | t: 1-773-384-7765 | f: 1-773-384-5115 | www.triliteinc.com | Designers and manufacturers of specialty electrical products. Since 1922.
WIRING DIAGRAM for MODELS
SG10-RG (Incandescent) and SG10-RG-LED
This wire used on
Incandescent 120 VAC
units only
CHASSIS
GROUND
Internal Connection
(Do Not Modify)
External Connection
X2
Capacitor
(Incandescent Only)
SG10-12RG VDC UNIT
SG10-24RG VAC/VDC UNIT
RED (+)
RED
BLACK (-)
GREEN
RED (+)
(LABELED 'GREEN')
953063 | REV B
