Tegan Lighting ARRI 3-S Installation Instructions

24vdc led surface monopoint

ARRI 3-S

24VDC LED Surface Monopoint

1. CAUTION: Read all instructions.

• Do not install any Spotlight closer than six inches from any curtain or similar combustible material.

• Do not install this system in a damp or wet location.

• Turn off electrical power before modifying the lighting system in any way.

• Ensure the Spotlight connector is attached correctly to the system with no cross threading and is tightened down completely to make contact

with the top of the track.

• Ensure all connections are tight. Loose connections can cause overheating, arcing and a potential fire risk.

• Use only as described in these Tegan Lighting Installation Instructions.

• Use only Tegan Lighting supplied accessories.

• Luminaires may be extremely hot, allow to cool before touching.

• These are 24VDC Spotlights; they must be connected to an appropriate 24VDC power supply. Refer to Specification Sheets.

• For proper installation, have a qualified electrician install this product.

• This luminaire must be wired and grounded in accordance standard accepted electrical installation practices, local codes, and ordinances.

• Wire supply connections must be made with U.L. or comparible testing agency-approved connectors.

• Regular cleaning of these products is important. Switch off at main supply and allow to cool before touching. Clean fittings with a soft damp

cloth and allow to dry before reconnecting power supply.

415-504-3536

www.teganlighting.com

•

ARRI 3-S Surface LED (ARRI 3-S)

• 415-504-3536 TG-INS-ARRI-3-S 8/16/18

info@teganlighting.com

Tegan Trac

Installation Instructions

Table of Contents

Need help?

Do you have a question about the ARRI 3-S and is the answer not in the manual?

Page 1 • Ensure all connections are tight. Loose connections can cause overheating, arcing and a potential fire risk. • Use only as described in these Tegan Lighting Installation Instructions. • Use only Tegan Lighting supplied accessories.
Page 2 Cover 1. Mechanical Installation • Loosen the 3 set Screws and cover to disassemble the ARRI 3-S. • Make wire connections inside ceiling or wall with wires passing through base. • Use screws to install base onto ceiling or wall.
Page 3 ARRI 3-S Tegan Trac 24VDC LED Surface Monopoint Installation Instructions Optic Media Media Holder 3. Removing and Installing the LED Optic • Unscrew front shield to install an alternative optic. • Line up the optic’s “pegs” with indents on LED board. Screw shield onto body until connection is flush.
