bonitron M3660REM Customer Reference Manual

Regenerative energy monitor

Advertisement

Quick Links

Model M3660REM
Regenerative Energy Monitor
Customer Reference Manual
Web: www.bonitron.com
Tel: 615-244-2825
Email: info@bonitron.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M3660REM and is the answer not in the manual?

Questions and answers

Summary of Contents for bonitron M3660REM

  • Page 1 Model M3660REM Regenerative Energy Monitor Customer Reference Manual Web: www.bonitron.com ● Tel: 615-244-2825 ● Email: info@bonitron.com...
  • Page 2 Bonitron has seen thousands of products engineered since 1962 and welcomes custom applications. With engineering, production, and testing all in the same facility, Bonitron is able to ensure its products are of the utmost quality and ready to be applied to your application.
  • Page 3 RIVE PTIONS In 1975, Bonitron began working with AC inverter drive specialists at synthetic fiber plants to develop speed control systems that could be interfaced with their plant process computers. Ever since, Bonitron has developed AC drive options that solve application issues associated with modern AC variable frequency drives and aid in reducing drive faults.
  • Page 4 M3660REM This page intentionally left blank.
  • Page 5: Table Of Contents

    NTRODUCTION 1.1. Who Should Use ........................... 7 1.2. Purpose and Scope ........................7 1.3. Manual Version and Change Record .................... 7 Figure 1-1: M3660REM......................7 1.4. Symbol Conventions Used in this Manual and on Equipment ............. 8 2. P ..................9...
  • Page 6 M3660REM This page intentionally left blank.
  • Page 7: Introduction

    URPOSE AND COPE This manual is a user’s guide for the model M3660REM. It will provide the user with the necessary information to successfully connect and operate the M3660REM. In the event of any conflict between this document and any publication and/or documentation related to any associated hardware (capacitor bank, etc.), the latter...
  • Page 8: Symbol Conventions Used In This Manual And On Equipment

    M3660REM 1.4. YMBOL ONVENTIONS SED IN THIS ANUAL AND ON QUIPMENT Earth Ground or Protective Earth AC Voltage DC Voltage DANGER: Electrical hazard - Identifies a statement that indicates a shock or electrocution hazard that must be avoided. DANGER! DANGER: Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss.
  • Page 9: Product Description / Features

    The M3660REM monitors the voltage and current seen by the load resistor; this allows it to characterize a braking Event by measuring the peak and average currents as well as calculating the total energy in the Event.
  • Page 10: Part Number Breakdown

    O D E U R RE N T AT I N G ODEL UMBER The base model number for all Regenerative Energy Monitors is M3660REM. YSTEM OLTAGE ATING The System Voltage rating indicates the maximum AC system voltage for which the unit is designed to operate.
  • Page 11: General Specifications

    User’s Manual 2.3. ENERAL PECIFICATIONS Table 2-3: General Specifications Table ARAMETER PECIFICATION System Voltage Up to 600 VAC Braking Current 200A / 2000A DC Controls Six display soft keys Display Four line, eighty character LCD (4x20) Unit Size (H x W x D) 13.4"...
  • Page 12: General Precautions And Safety Warnings

    M3660REM 2.4. ENERAL RECAUTIONS AND AFETY ARNINGS  F OR USE BY QUALIFIED AND TRAINED PERSONNEL ONLY  IMPROPER OPERATION PRODUCT IGNORING THESE WARNINGS RESULT SERIOUS BODILY INJURY OR DEATH!  B M3660REM EFORE CONNECTING BRAKING RESISTOR TERMINALS ENSURE THAT THE SYSTEM IS POWERED ELECTROCUTION ...
  • Page 13: Installation Instructions

    NSTRUCTIONS 3.1. NVIRONMENT While closed, the M3660REM is water, dust, and crush resistant. When open and in operation, the unit should be used only in dry, clean areas. Ensure that the interior of the unit casing is kept dry. 3.2.
  • Page 14 M3660REM This page intentionally left blank.
  • Page 15: Operation

    UNCTIONAL ESCRIPTION The M3660REM is an analysis tool to help system designers get a better understanding of the characteristics of their braking Events. It should be attached to the load resistor terminals, not to the DC Bus directly; this way it only measures the actual braking energy.
  • Page 16: Features

    AC P 4.2.1.1. OWER NPUT ONNECTOR The M3660REM is equipped with a standard IEC C14 connector for input power. This connector mates with a standard C13 cable, commonly used with desktop computers, to provide power to the unit. 4.2.1.2. OLTAGE...
  • Page 17: Display

    User’s Manual 4.2.2. ISPLAY The digital display presents the user with information about the present status of the system, including the voltage and current. The display also presents the user with options to control system operation. 4.2.2.1. IRECTIONAL UTTONS Each of the four buttons corresponds to a direction: up, down, left or right. Up and Down move the cursor among menu items.
  • Page 18: Screens & Menu Navigation

    M3660REM & M 4.2.3. CREENS AVIGATION Many screens are menus allowing access to other screens, or lists presenting a number of options. The presently selected item on the menu is indicated by a ‘>’ cursor. This selection indicator is moved using the Up and Down buttons.
  • Page 19 User’s Manual Figure 4-3: Menu Tree Individual Events Records Lifetime Stats Date/Time Main Configuration Menu Set Current Clamp Clear Event Records Clear Status Records Clear All Data...
  • Page 20: Troubleshooting

    If a problem persists after following the steps below, contact the product supplier or your system integrator for assistance. Repairs or modifications to this equipment are to be performed by Bonitron approved personnel only. Any repair or modification to this equipment by personnel not approved by Bonitron will void any warranty remaining on this unit.
  • Page 21 User’s Manual This page intentionally left blank.
  • Page 22: Engineering Data

    M3660REM NGINEERING 6.1. ATINGS HART Table 6-1: Ratings Chart Input Voltage 110 - 120VAC System Voltage 600VAC Max Braking Voltage 1000VDC Max Braking Current 2000A Table 6-2: Dimensions Height 6 in. (with top closed) Width 13.4 in. Depth 11.6 in.
  • Page 23 User’s Manual This page intentionally left blank.
  • Page 26 D_M3660REM_CMAN_VALL_00a 12/03/2018 521 Fairground Court ● Nashville, TN 37211 ● USA Tel: (615) 244-2825 ● Fax: (615) 244-2833 ● Web: www.bonitron.com ● Email: info@bonitron.com...
