Wozart Aura WASI03 User Manual

Hide thumbs Also See for Aura WASI03:
Table of Contents

Advertisement

Quick Links

Download this manual
aura
SWITCH
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aura WASI03 and is the answer not in the manual?

Questions and answers

Related Manuals for Wozart Aura WASI03

Summary of Contents for Wozart Aura WASI03

  • Page 1 aura SWITCH User Guide...

  • Page 3: Table Of Contents

    Contents Aura..............................05 What is in the box?..........................06 Aura Switch............................07 Setup Guide............................08 Accessory Configuration........................13 How to Use............................16 Troubleshooting............................25 Frequently Asked Questions(FAQs).....................28 Warranty and Service..........................31...
  • Page 4 Thank You We hope you enjoy your purchase. We at Wozart have carefully crafted a reliable, durable and secure Smart Home product. We promise to toil harder to build great devices which make life easier and the planet more livable. We hope our association continues and grows stronger with each passing day.

  • Page 5: Aura

    Aura's minimalistic design makes installation of products easy and hassle free. Wozart's products are built with the goal to enhance and simplify everyday life while protecting the environment.

  • Page 6: What Is In The Box

    What is in the box? 1. Aura Switch 2. Switch connector aura SWITCH 3. User manual 4. Setup Code sticker Fig. 01...

  • Page 7: Aura Switch

    aura SWITCH Aura Switch is a retrofittable device which fits behind your standard wall switch board. With Aura Switch installed, you can enjoy a multitude of features such as controlling appliances through voice, mood based scene settings, appliance scheduling and Geo-location based control. WASI03 Model Input...

  • Page 8: Setup Guide

    Setup guide Load Connections · Connect neutral wire behind switchboard to terminal of Aura Switch. · Connect live wire behind switchboard to terminal of Aura Switch. · Connect inverter wire to terminal of Aura Switch. If no inverter wire is available, connect another live wire to terminal .
  • Page 9 Fig. 02 shows electrical wiring before installing Aura Switch Fig. 02...
  • Page 10 Switch connections Plug switch connector provided in the box to the switch socket of Aura Switch. · Following are the colours of the wires that have to be connected to the switches · and the respective loads they control. · Ground Yellow ·...
  • Page 11 Fig. 03 shows Load and Switch connections after installing Aura Switch. Fig. 03...
  • Page 12 Fig. 04 shows power supply connection if inverter wiring isn't available Fig. 04...

  • Page 13: Accessory Configuration

    Accessory Configuration Open the Home app and tap Add Accessory or tap (Fig. 05). When Aura Switch device appears, tap it. If asked to Add Accessory to Network, tap Allow (Fig. 06 & Fig. 07). Fig. 05 Fig. 06...
  • Page 14 · With the camera on your iOS device, scan the eight-digit on the Setup code sticker provided (Fig. 07). · Tap Enter Code Manually enter the code on Setup Code Sticker provided in the box. Note : We recommend you stick the Setup Code Sticker provided at an accessible location such as Switchboard Panel.
  • Page 15 · Add information about your appliance, like its name or the room it is located in. Siri will identify your appliance by the name you give it and the location it is in (Fig. 08). Tap Next · Repeat the above step for all the appliances and Done ·...

  • Page 16: How To Use

    How to Use App Control In the Home tab or rooms tab, tap on an appliance to turn it on or off. For Lights which support brightness control, touch and hold the appliance to regulate brightness. (Fig.10) Appliances can be controlled from Control center or your Apple Watch if they are added as Favorite Accessories.
  • Page 17 Scenes Scenes let you control multiple accessories at the same time. For example, a scene called “Good Night” can be created that turns off all lights and switches on the AC, all with a single tap. Scenes can be triggered by tapping on the scene or by asking Siri.
  • Page 18 Voice control After you add accessories to Home, you can control your accessories and scenes with Siri Commands. All Accessories and scenes can be called by the name you have given and location you have placed them Few Siri Commands ·...
  • Page 19 Shared Control You can invite others to control your accessories if they are using iOS10 & above and signed into iCloud. To invite others Open Home and tap the Home tab. · in the upper-left corner. · Tap Invite. · Enter the person's Apple ID that they use with iCloud.
  • Page 20 Set up your home hub You can set up your HomePod, Apple TV 4K, Apple TV (4th generation), or iPad as a home hub to automate and remotely control your HomeKit accessories from your iOS device. Fig. 14 The device you set up as home hub must remain in your home, connected to your home WiFi network, and powered on.
  • Page 21 Set up HomePod as a home hub HomePod automatically sets itself up as a home hub so you can control your HomeKit accessories remotely with the Home app and use automations. Just make sure that the iOS device you use to set up HomePod is signed in to iCloud with the Apple ID that you used to set up your HomeKit accessories in the Home app.
  • Page 22 Set up Apple TV as a home hub · On your iOS device or Mac, set up two-factor authentication for your Apple ID Then go to iCloud and make sure that you have iCloud Keychain turned on. · On your Apple TV, go to Settings > Accounts and make sure that you're signed in to iCloud with the same Apple ID as your iOS device.
  • Page 23 Automate your accessories · Open the Home app, tap the Automation tab, then tap Create new Automation. · Choose when you want the automation to occur a. My Location Changes: Have accessories and scenes turn on or off when you arrive or a leave a location.
  • Page 24 · Select scenes and accessories to automate. Then tap Next. · Verify the accessories and scenes. Touch and hold an accessory or scene to adjust its settings. · To finish, tap Done. Turn off or delete automation · Open the Home app and tap the Automation tab. ·...

  • Page 25: Troubleshooting

    Factory reset the device as explained below; remove the accessory before reconnecting the accessory. Note*: If factory reset is done, all your customizations are lost. Do it only if all options fail. info@wozart.com 040-6745 4555. If you need further assistance write to us at...
  • Page 26 Normal reset Toggle the switch connected to orange wire of switch connector (Load1) eight times continuously then you hear a buzzing sound or in case the switch panel is open, press the button with letters “NR” marked on the device or Switch off and back on, the MCB for the room which has the device to be reset. Factory reset Toggle the switch connected to red wire of switch connector (Load2) eight times continuously then you hear buzzing sound twice or in case the switch panel is open, press the button with letters marked “FR”...
  • Page 27 After Factory Reset is done, Go to Wi-Fi settings. 1. If ‘Aura Switch –XXXXXX’ is listed as shown in Fig.17 then proceed with accessory configuration. 2. If ‘Aura Switch-XXXXXX-Android’ is listed as shown in Fig.18, factory reset once again to configure Aura Switch with your iOS device.

  • Page 28: Frequently Asked Questions(Faqs)

    Frequently Asked Questions (FAQs) 1. Do I have to change my switchboard? No. Aura Switch is a complete retrofit solution and it goes right behind your existing switchboards without any additional rewiring. 2. Will my mechanical switches stop working if I use your product? No.
  • Page 29 Precautions · Do not connect heavy loads to load terminals L1, L2 and L3. · If non dimmable appliances are connected to terminals L1, L2 and L3, do not regulate their intensity from the app. If it is done the appliances lifetime may get affected. ·...
  • Page 30 Declarations All Aura products are proprietary of Wozart Technologies Private Limited. All rights reserved. Without prior approval of Wozart Technologies, reproduction, transfer, distribution or storage of contents in this document in any form is prohibited. Wozart Technologies operates a policy of ongoing development.

  • Page 31: Warranty And Service

    Resellers are not authorized to extend any other warranty on Wozart's behalf. Service for all Aura products will be provided for device life time. To obtain service, contact nearest authorized Aura...
