Summary of Contents for Kellfri 21-KW1000
- Page 1 21-KW1000 RADIO REMOTE-CONTROLLED HYDRAULIC WINCH CAREFULLY READ THE OPERATING INSTRUCTIONS BEFORE USING THE PRODUCT! OPERATING INSTRUCTIONS TRANSLATED FROM THE ORIGINAL...
-
Page 2: Table Of Contents
Table of Contents Product information Technical specification Safety information In case of emergencies Personal protection Surroundings Warning decals Measures before use Instruction: using the winch Connection diagram to the valve assembly Connection diagram - Winch and drive Connection diagram- Winch Storing,Service and maintenance Exploded diagram: Winch Radio controlled winch... -
Page 3: Product Information
INTRODUCTION Thank you for choosing a product from Kellfri AB. By following the general safety information and the instruction manual and by using common sense, you will have a great and safety use of your Kellfri product for many years. Kellfri designs and delivers effective, affordable ma- chinery and components for forest, agriculture, construction and gardening in Sweden, other Nordic countries and Europe. -
Page 4: Safety Information
If the instructions manual is damaged or otherwise unusable If the instructions manual is dam- aged or otherwise unusable, please contact your retailer. For more information visit our website: https://www.kellfri.co.uk/ Do not use this equipment if you are feeling sick, tired or in influence of alcohol. Nor if you are under the influence of strong medications or drugs, suffering from strong depression or severe mental illness. -
Page 5: Incase Of Emergencies
INCASE OF EMERGENCIES In case of an emergency please dial 112. Keep cell phone or emergency phone available specially when working alone. First aid kit and fire extinguishers must be kept easily accesable during all work, maintenance and service. PERSONAL PROTECTION Always wear suitable clothing and footwear. -
Page 6: Warning Decals
WARNING DECALS Make sure warning decals are always visible and clean them when necessary. Do not use a high-pressure washer directly on the warning label. If a decal becomes worn or in any other way unusable, order a new set of decals. SYMBOL EXPLANATION Read the instruction manual! Before work begins. -
Page 7: Measures Before Use
SAFETY MEASURES BEFORE USE Read the safety information and instruction manual carefully. Be sure you understand the safety measures, instruction manual and warning labels. Use common sense when operating the machine and use appropriate personal protective equipment. Always check the performance and the machine combination that are used. It’s highly impor- tant these matches in a satisfactory manner. -
Page 8: Connection Diagram To The Valve Assembly
Winch Cyl. B Cyl.A Right Left Rotator Turn cylinder Grapple Fold Outrigger Outrigger Lift... -
Page 11: Storing,Service And Maintenance
Be awarew that the winch valve is not prepared for constant pressure system type • Operate and check all movements Kellfri AB is working continuously to further develop its products and therefore reserves the right to modify the design and appearance among others without prior notice. STORAGE Always keep the tool or product in a dry place, preferably under cover when not in use. -
Page 12: Exploded Diagram: Winch
21-KW1000 Specification Motor Wire reel Sleeve Motor bracket Bracket Mounting bracket for wire reel Bolt M8x32 Bolt M10x40 - countersunk head Bolt M10x12 - countersunk head... -
Page 13: Radio Controlled Winch
RADIO CONTROLLED HYDRAULIC WINCH TRANSMITTER TX1-A Frequency (MHz) 433.087- 434.662 Channels Fixed individual code Functions Inbuilt antenna Operating voltage 3 AA (LR03) Power consumption ~20 mA IP class IP65 RECEIVER Frequency (MHz) 433.087- 434.662 Channels Scans individual codes Winch depending on model Relay outlets Antenna External BNC... -
Page 14: Product Information: Radio Remote Control
PRODUCT SAFETY INSTRUCTIONS • Read the operating manual carefully before installing and using the product • Only qualified staff are allowed to install the product • Turn off the power to the receiver before connecting the equipment • Check that you have connected the correct terminal block •... - Page 15 Receiver RX1 Relay LED 1-3 Function relay 1-3 Quick fuse 10 A Terminal block for voltage Antenna contact Code storage LED (red) Power supply (yellow) Function button Coding button 10. Select button SNABBSÄKRING 3. Options: Quick fuse NOTE: With a 10 A fuse fitted and the receiver connected, the operating voltage from the terminal block (12-24 V AC/CD) in the centre is supplied with current from fuse number 1 (terminal block no.
-
Page 16: Frequencies
CHANGING FREQUENCY BANK The transmitter is preset in Channel 1 Bank 1 The frequency bank is changed in the transmitter before it is paired with the receiver. If a receiver has already been paired with the transmitter, the receiver must be deleted and the frequency bank changed before the transmitter can be paired again. - Page 17 CHANGING FREQUENCY Start the transmitter Press the OFF button and keep it pressed Within 3 seconds: Press the ON button: Keep both buttons pressed Release both buttons Within 5 seconds: a. Press the transmitter’s IN button to move up a row in the frequency table (see the frequency table) b.) Press the transmitter’s OUT button to move down a row in the frequency table (see the frequency table)
-
Page 18: Locking And Installation Document
INTERLOCKING When interlocking is activated, only one relay can be activated at a time. If interlocking is not activated, all relays can be activated at the same time. STANDARD: Interlocking deactivated (receiver Function LED = turned off ) TURNING OFF INTERLOCKING Start the transmitter and receiver Press the receiver function button The transmitter function LED lights up green when interlocking is activated. -
Page 19: Complaint Form
Complaint form We are grateful for your help pointing out any inaccuracies in the Kellfri product delivered to you. Before making a complaint read Kellfris general warranty and sales conditions in our catalog as well as the enclosed User’s manual that comes with the machine. -
Page 20: Warranty And Ec Declaration Of Conformity
Other equipment must meet the hardware requirements of the Directive. Tina Baudtler, VD Kellfri AB is constantly working on further developing their products and therefore reservesthe right to modify, among other things the design and appearance without notice. CUSTOMER SERVICE You are always welcome to give your feedbacks, reviews or ask us about our tools and products.
