- Page 1 .3X.6C Englisch Operating Manual Dissolved Oxygen – Measuring transducer OXY 3610 MP Companies / Brands of the GHM www.ghm-group.de Keep for later use.
-
Page 2: Table Of Contents
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 2 von 14 Contents SAFETY ..................................3 ..............................3 ENERAL NOTE ..............................3 NTENDED USE ..............................3 UALIFIED STAFF ..........................3 AFETY SIGNS AND SYMBOLS ........................4 EASONABLY FORESEEABLE MISUSE ................................4 UITABILITY 1.6.1... -
Page 3: Safety
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 3 von 14 Safety 1.1 General note Read this document carefully and get used to the operation of the device before you use it. Keep this document within easy reach near the device for consulting in case of doubt. -
Page 4: Reasonably Foreseeable Misuse
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 4 von 14 1.5 Reasonably foreseeable misuse This device must not be used at potentially explosive areas! Do not use these products as safety or emergency stop devices or in any other application where failure of the product could result in personal injury or material damage. -
Page 5: During Normal Operation
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 5 von 14 1.6.2 During normal operation Do not use this product as safety- or emergency- stop devices or in any other application where failure of the product could result in personal injury or material damage. -
Page 6: Installation And Commissioning
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 6 von 14 3 Installation and Commissioning 3.1 General installation instructions Loosen screws (A). Remove cover (B) Wall mounting screws (C) are not included. The mounting-hole-diameter is 4.2 mm. See pattern drilling above (50 x 70 mm). -
Page 7: Assignment Of Elbow-Type Plug
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 7 von 14 4 Assignment of elbow-type plug Description of the contacts. 1= supply voltage +Uv 2= GND / signal 2-wire connection (4-20mA) 1 = signal + 3 = supply voltage +Uv... -
Page 8: Calibration Of The Oxygen Measuring Transducer
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 8 von 14 6 Calibration of the oxygen measuring transducer Expose electrode to the ambient air, wait until the temperature has adapted to the ambient conditions. Parameter button 1 < Description 5sec After approx. -
Page 9: Average Ambient Absolute Pressure "Pabs
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 9 von 14 Average ambient absolute pressure “PABS“ 7.1.2 Parameter Value Description button 1 button 2 / 3 500 2000 Necessary for a correct evaluation of the state of the electrode. If the... -
Page 10: Offset Settings For Different Applications
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 10 von 14 9 Offset settings for different applications The Offset setting is supposed to correct measuring deviations caused by different flow speed (v) around the elec- trode: For activated sludge basins and at flow speeds > 1m/s an offset Fü... -
Page 11: Design
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 11 von 14 11.1.2 Design Replenishing hole Electrode shaf Diaphragm Protective flask The electrode housing is made of ABS. With the exception of the electrode shaft all parts need to be maintained regularly and be replaced if necessary. -
Page 12: Electrode Maintenance
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 12 von 14 Unless it is used the electrode is to be stored in the protective flask filled with water or directly in a vessel filled with dechlorinated water. Residues of bacteria, fungi or algae must be removed prior to measuring using a soft paper towel. -
Page 13: Decommissioning, Reshipment And Disposal
T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 13 von 14 12 Decommissioning, Reshipment and disposal 12.1 Decommissioning Always disconnect the device before from its supply before decommission e.g. at fuse. Valid general safety require- ments shall be observed. - Page 14 T02.0.3X.6C-07 Mounting and operating manual OXY 3610 MP Page 14 von 14 Storage temperature -20 ... 70 °C (electrode 0 ... 60 °C) Housing ABS (IP65 - with the exception of electrode and temperature probe con- nection sockets) Dimensions 82 x 80 x 55 mm (without elbow-type plug and sensor sockets)
