Summary of Contents for SIGMA TEK 1U619-001
- Page 1 SIGMA TEK, INC. 1U619-001 COMM / NAV / DME / ATC RADIO CONTROL PANEL INSTALLATION MANUAL 86M066 Pub. No. Issue...
- Page 2 1U619-001 COMM / NAV / DME / ATC CONTROL PANEL LIST OF EFFECTIVE PAGES Original Release ..A ....July 1993 Revision....B....September 1999 Revision....C ....October 2002 Subject Page No. Revision Table of Contents General Information Installation " Wiring Diagram...
-
Page 3: Table Of Contents
1U619-001 COMM / NAV / DME / ATC CONTROL PANEL TABLE OF CONTENTS Section Title Page No. 1.0 General Information ..................2 1.1 Introduction ....................2 1.2 Description Of Equipment ................2 2.0 Installation......................3 2.1 Introduction ....................3 2.3 Unpacking ....................3 2.4 Inspection .................... -
Page 4: General Information
Aircraft Company. DESCRIPTION OF EQUIPMENT The 1U619-001 Control Panel is designed to provide remote tuning of two VHF COMM Transceivers, two VHF NAV / DME Receivers and one or two Air Traffic Control Transponders. The Control Panel is capable of tuning within a VHF COMM frequency range of 118.00(0) to 136.990 MHz in 25 KHz or 8.33 KHz increments (switch selectable). -
Page 5: Installation
After the connectors have been checked for successful mating, place the Control Panel in the opening provided for it. Using the seven (7) screws, securely fasten the unit. Note: Connector J6 on the 1U619-001 Control Panel is not used in this installation. This connector has a metal cover installed, which should not be removed. - Page 6 1U619-001 COMM / NAV / DME / ATC CONTROL PANEL Apply power to the 1U619-001Control Panel and the radios. The displays should show the last frequencies selected when the Control Panel was last powered down. The Comm displays should show frequencies within the range of 118.00 to 136.97 (or 151.975) MHz. The Nav display should show frequencies of 108.00 to 117.95 MHz.
-
Page 7: Figure 1 Installation Wiring Diagram
Two (2) additional wires must be added to the existing aircraft harness (J4) before installing the 1U619-001 Control Panel. Connector J4 pin “b” must be connected to the 28 vdc power input to Xponder radio # 1. Connector J4 pin “Z” must be connected to the 28 vdc power input to Xponder radio # 2 (if installed). -
Page 8: Technical Specifications
1U619-001 COMM / NAV / DME / ATC CONTROL PANEL 3.0 TECHNICAL SPECIFICATIONS PHYSICAL CHARACTERISTICS Dimensions: 7.65” W x 6.90” H x 6.00” D Weight: 8.0 pounds maximum Displays: 5½ digit dual line Liquid Crystal Display, White digits on black... -
Page 9: Figure 2 Outline Configuration
1U619-001 COMM / NAV / DME / ATC CONTROL PANEL Figure 2 Outline Configuration Pub. No. 86M066 Page 7 Issue... -
Page 10: Connector Pin List
1U619-001 COMM / NAV / DME / ATC CONTROL PANEL CONNECTOR PIN LIST J1 (Comm 1) MS3122A20-41P & J2 (Comm 2) MS3122A20-41PW Panel Connector Description Description spare Audio In Hi “B” Serial Data In Audio Out Arm “A” Serial Data In... - Page 11 1U619-001 COMM / NAV / DME / ATC CONTROL PANEL J4 (ATC Transponder) MS3122A18-32PX Panel Connector Description Description Code Select Wire B (A1) Ident Code Select Wire C (A2) Transponder #1 On Code Select Wire D (A4) Transponder #2 On...
