Summary of Contents for CHIEF KBD-UC-UC
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Ultra-compact Keyboard Trays Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description KBD-UC-UC...
-
Page 2: Important Safety Instructions
10 lbs (4.5 kg). is attached. ACCESSORY: AN ACCESSORY is the secondary Chief product which is attached to a primary Chief product, and may WARNING: Use this mounting system only for its intended have a component attached or setting on it. -
Page 3: Installation Instructions
Installation Instructions KBD-UC-UC TOOLS REQUIRED FOR INSTALLATION 1/8" (3.17mm) PARTS B (1) [Mouse pad] A (1) C (1) [Keyboard tray] [Mouse fence] E (1) F (20) [Bumper] (not used) #8 x 5/8" D (1) G (1) [Under-desk track] [Track guard]... -
Page 4: Assembly And Installation
KBD-UC-UC Installation Instructions Assembly And Installation Install back guard (L) with four #8 x 5/8" wood screws (F). (See Figure 3) Use four #10-24 x 1/4" Phillips machine screws (H) and four acorn nuts (J) to secure keyboard tray (A) to keyboard mechanism arm (K). - Page 5 Installation Instructions KBD-UC-UC Slide keyboard tray (A) into under-desk track (D). (See Figure 5) Figure 5 Use three #8 x 5/8" wood screws (F) to secure track guard (G) to under-desk track (D) and desk. (See Figure 6) turn knob...
- Page 6 KBD-UC-UC Installation Instructions...
- Page 7 Installation Instructions KBD-UC-UC...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
