Preparation For Use - eBEAM edge+ Quick Setup

1 2
Use the 1m USB charging Connect your projector
to your computer.
cable to charge your Edge+
Stylus with any USB
power adapter.
Once fully charged, your
stylus can be used
continuously for up to
15 hours.
7
*Note: You also can place
Hold the sensor and
the sensor directly onto prepare to place it carefully
magnetic surfaces without in the indicated location.
using the plate.
Allow a 5cm margin
between the sensor and
writing area.
3
Turn on your projector and
align/focus the image on
the projected surface.
8
Place the sensor so that it
is centered vertically on the
projected surface, parallel
to the projection edge.
4 5
Place a mounting plate
Connect the micro USB
cable to your Edge+ Sensor. onto the back of the sensor
with the Command
adhesive side facing out.
*(See note for magnetic
mounting option)
9 10
Connect the Edge+ USB
After the eBeam software is
cable to your computer's
launched, calibrate the system.
USB port. Install and run the
Congratulations!
eBeam software.
Your eBeam Edge+ system is
Download at:
now ready for use.
http://www.e-beam.com/
portal/download-software.html
6
Peel the Command adhesive
backing from the sensor.
