Summary of Contents for SE Devices Z-Wave Series
- Page 1 SE Devices - FMS01 Modular Z-Wave Devices Installation Manual Page 1...
-
Page 2: Disclaimer And Warning
MAX higher than 25 degrees unless it is absolutely necessary. Due to this same fact, SE Devices can not be held responsible for any damage to heated floors controlled by the thermostat functionality of the devices, even when configuration and installation is technically correct. -
Page 3: Device Components
SE Devices – Modular Z-Wave Devices – Installation Manual Device Components A functioning Z-Wave device is assembled using at least 4 separate parts: Front Units – Provides the Userinterface Mounting Frame – Fixes the Front Unit to the wall Back Unit – Provides the Electrical interface (dimmer or relay), and power for the Front Unit Back Unit Mounting Bracket –... - Page 4 SE Devices – Modular Z-Wave Devices – Installation Manual Front Units There are currently two Front Units available: FMS-01 – Multifunction Switch Z-Wave The Multifunction Switch provides four push buttons which can be configured in 1, 2 or 4-way mode.
-
Page 5: Assembly And Installation
… or a Cascade Connector to connect to an adjacent unit Frames available for Installations There are currently Four (4) different Mounting Frames available from SE Devices. The difference between the Frames is the number of Front Units (Multifunction Switch and Wheel Controller) which can be fitted in one frame. - Page 6 SE Devices – Modular Z-Wave Devices – Installation Manual Before Installation Begins Please consider the following before starting the Physical installation: If a Room Temperature sensor will be fitted, this MUST be connected to the Bottom Unit in a frame. Take this into consideration when mounting devices for Thermostat use.
- Page 7 SE Devices – Modular Z-Wave Devices – Installation Manual Installing Back Units Select a Mounting Frame appropriate for the number of devices which will be installed at one single location (1,2, 3 or 4 unit frame. Make sure all Back Units which should be placed behind the frame is at hand.
-
Page 8: Wiring Diagram
SE Devices – Modular Z-Wave Devices – Installation Manual Wiring Diagram The Back Units should be wired according to this diagram. 230V Dimmer 1-10V Dimmer 1P/2P Relay 1-10V LOAD MAINS LOAD MAINS NEG POS GND IN Floor Sensor 1-10V Driver... - Page 9 SE Devices – Modular Z-Wave Devices – Installation Manual Installing Front Units When the Back Units and Frame is in place, Front Units can be installed. If multiple Front Units are installed in the same frame, always start with the lower Front unit first, and work your way upwards.
- Page 10 SE Devices – Modular Z-Wave Devices – Installation Manual Disassembling installed units In case a part of the modular unit needs replacement or changes, it is necessary to disassemble the unit. Note that the following procedures should ONLY be executed by a certified electrician, as the unit is connected to mains voltage.
- Page 11 SE Devices – Modular Z-Wave Devices – Installation Manual Remove the Wires from the Mains Connector Use a small flat head screwdriver, and firmly push down the orange release mechanism above the wire. Pull the wire gently to free it from the Connector. Repeat until all wires are free from the Connector.
