Installation & Operation Manual

CD1500P • CD2000P

Corona Discharge Ozone Generators

Tested and certified by

WQA to NSF/ANSI 50 as a

Tested and certified by

WQA to NSF/ANSI 50 as a

component only.

ClearWater Tech, LLC.

Integrated Ozone Systems

850-E Capitolio Way, San Luis Obispo, Ca 93401 • 805-549-9724 • Fax: 805-549-0306 • E-mail: service@cwtozone.com • www.cwtozone.com

Table of Contents

Need help?

Do you have a question about the CD1500P and is the answer not in the manual?

Questions and answers

Manuel Salcido

May 12, 2025

ozonator green lights are on but there is not ozone output there is just air coming out from system

1 comments:

Mr. Anderson

May 20, 2025

The cause could be a loss of continuity in the external loop. When the external loop loses continuity, the main power and cooling fans stay on (green lights remain), but ozone output stops. This interrupts ozone production and turns off the “Ozone Output” LEDs, even though the unit appears powered.

This answer is automatically generated

Summary of Contents for CleanWater Tech CD1500P

Page 1 Ozone Systems Installation & Operation Manual CD1500P • CD2000P Corona Discharge Ozone Generators Tested and certified by WQA to NSF/ANSI 50 as a Tested and certified by WQA to NSF/ANSI 50 as a component only. component only. ClearWater Tech, LLC.
Page 2: Ozone Generator
ClearWater Tech ozone systems are designed for safe, effective use in a variety of water treatment applications. The CD1500P, and CD2000P ozone generators have been tested and certified by the Water Quality Association according to NSF/ANSI 50. Each complete, integrated system may include the following components required for reliable, efficient ozone production and can be divided into four general segments: •...
Page 3 Theory of Operation/Product Description (continued) Depending on the application, the ClearWater Tech ozone generator may be interlocked with an ORP controller, PPM controller, pressure switch, timer or circulation pump. Other safety features are also built in, including thermal protection. Ozone Injection/Contacting The ozone injector serves two purposes: One, it creates the vacuum required to safely draw the ozone gas from the ozone generator and two, it provides a means by which the ozone gas can become...
Page 4: Safety Warnings
SAFETY INFORMATION CHAPTER 2 SAFETY WARNINGS Two aspects of ClearWater Tech ozone generators represent potential dangers – ozone gas and high voltage electricity. OZONE GAS - WARNING: HIGH CONCENTRATIONS OF OZONE GAS ARE DANGEROUS TO HUMANS. LOW CONCENTRATIONS CAN CAUSE IRRITATION TO THE EYES, THROAT AND RESPIRATORY SYSTEM.
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS. All electrical connections should be made by a licensed, qualified electrician. Before attempting any electrical connections, be sure all power is off at the main circuit breaker. Install all electrical equipment at least five feet from any open body of water using non-metallic plumbing.
Page 6: Equipment Placement
INSTALLATION PROCEDURES - Getting Started CHAPTER 3 Unpacking Compare the ozone system equipment received to the packing list provided. Before beginning any installation procedures, thoroughly inspect all components for damage. If damage is noticed, promptly notify the freight carrier and request an on-site inspection. Inspect all packing materials for small parts before discarding.
Page 7 INSTALLATION PROCEDURES – Plumbing CHAPTER 4 The ozone system should be plumbed using either a sidestream or full flow configuration. The sidestream loop method takes a portion of the water from the main flow (see Figure 4-1) and diverts it into a sidestream downstream of the filter (if so equipped). Ozone is introduced into the sidestream water and is allowed contact time with the water before it is returned to the main flow at a point downstream of all other equipment (heaters, solar panels, etc., if so equipped) in the circulation system.
Page 8 Plumbing (continued) column mounting kit and install according to the instructions below. If installing a contact tank, secure to a solid horizontal surface using mounting flange or feet. Step 8: Install the contact vessel venting system into the top of the vessel. If using the ClearWater Tech contact column, the vent kit supplied includes fittings, a control valve and Teflon®...
Page 9 Plumbing (continued)
Page 10: Installation Procedures - Electrical
“THIS CONNECTION IS A DRY CONTACT ONLY, DO NOT APPLY VOLTAGE”. Step 4: Ozone Output Control: The CD1500P and CD2000P ozone generators are equipped with two options for controlling the ozone output. The first option is a manual 0-100% ozone output control and the second is a remote 4-20mA control signal.
Page 11 Electrical (continued) Step 1: Mount the 4-20mA controller to a suitable vertical surface according to the installation manual supplied with the controller. Step 2: Wire the #22 AWG orange ‘positive’ (+) lead from the ozone generator to the 4-20mA controller according to the manual supplied with the controller.
Page 12 INSTALLATION PROCEDURES – Pneumatic CHAPTER 6 This section outlines the steps required to complete the enriched air (90% +/- 3% oxygen purity at -100˚F dew ozone system pneumatic hook-ups. system point). The air is drawn from the ozone generator (where components include the air preparation system, ozone ozone is produced from the oxygen in the air stream) and generator, vacuum break, and ozone injector manifold...
Page 13 Pneumatic (continued) Hook-Ups: Ozone generator-to-vacuum break & vacuum break-to-injector manifold The ClearWater Tech vacuum break provides a positive atmospheric “break” between the ozone injector manifold and the ozone generator, preventing water from flowing back into the ozone generator should the venturi check valve fail. Under normal operating conditions, the vacuum break's flapper valve (see Figure 6-3) is closed, allowing the vacuum created by the venturi to draw the output gas from the ozone generator.
Page 14 START-UP & CALIBRATION CHAPTER 7 The previous sections of this manual have involved comparatively static procedures – making electrical and pneumatic connections, fitting pipe, etc. This section involves the dynamic process of starting up and balancing the components of the ozone system, including initiating water flow, making air and water flow adjustments, etc.
Page 15 This will indicate that the contact vessel is full and only a very small amount of water is allowed to escape. Pneumatic Operating Parameters Figure 7-1 CD1500P Operating Range Optimum Air prep system air flow 5 to 6 scfh 6 scfh Ozone generator total air flow (gauge –...
Page 16: Maintenance
MAINTENANCE CHAPTER 8 Maintenance of the ozone system is critical to its longevity and operating efficiency. While all system components are built to provide years of reliable service with minimum maintenance, following the procedures outlined below is strongly recommended. All maintenance procedures have been segmented by interval: daily, monthly, semi-annual and annual. Daily procedures involve quick, visual checks for changes in normal operating conditions.
Page 17 Maintenance (continued) • Cover Filter: Check the cover filter element mounted on the side of the air preparation system and clean as required. Operating conditions in the equipment area will dictate the frequency required for this procedure. Remove the filter element and clean with soap and water, drying them completely before re-installing. Ozone Generator •...
Page 18 Unplug the electrical connections from the drive module. Step 3: Remove the 4-20mA control board with mounting bracket from the reaction chamber of the CD1500P. Step 4: Disconnect tubing connections from the fittings on both ends of the reaction chamber.
Page 19 Maintenance (continued) Step 10: With contact brush attached, remove the brush adapter nut from the high voltage end cap. Step 11: Inspect the dielectric, end caps and cathode for breakage, corrosion or debris. Clean and/or replace parts as necessary. If cleaning and/or parts replacement is not required, re-assemble the reaction chamber per the instructions below.
Page 20 Maintenance (continued) Vacuum Break • Cleaning: Disconnect ozone delivery lines. Remove the vacuum break from mounting clamps. Disconnect the overflow tube from flapper valve, open flapper and clean the seat with a soft cloth. Remove riser tube threaded fitting and flush riser tube with water. Re-assemble and re-install vacuum break, making sure to add water to correct level (see Figure 6-3).
Page 21: Troubleshooting
Maintenance (continued) TROUBLE SHOOTING CHAPTER 9 AIR PREPARATION PROBLEM/SYMPTOM POSSIBLE CAUSE SOLUTION Unit not operating - No power to system - Check main power to system - Power switch in “OFF” position - Turn switch to “ON” position - Incorrect wiring - See “Installation Procedures –...
Page 22 OZONE GENERATOR – continued PROBLEM/SYMPTOM POSSIBLE CAUSE SOLUTION Drive Module - Main Power - No power to drive module from power supply - Check main power to unit “Green” LED(s) not illuminated - Test voltage from power supply to drive module (see “Appendix – Drive Module Input Voltages”) - Check for loose wires or connectors - LED is not illuminated during startup sweep.
Page 23 Troubleshooting (continued) OZONE GENERATOR – continued PROBLEM/SYMPTOM POSSIBLE CAUSE SOLUTION Unit flooded with water - Defective check valve - Replace check valve(s) Ozone smell detected in or - Assess damage, repair as required near ozone generator - Insufficient vacuum at venturi - Adjust injector See “Start- Up &...
Page 24: Specifications
APPENDIX - CHAPTER 10 Section A Specifications Shown: ClearWater Tech OXS90 Air Prep System with Cover Shown: ClearWater Tech OXS90 Air Prep System with out Cover AIR PREP SYSTEM SPECIFICATIONS OXYGEN OUTPUT/SCFH OXS90 15.5” h x 17” w x 16” d, 45 lbs 90% (+/-3%) @ 12 scfh, 12PSI (Workhorse 12c) (with cover)
Page 25 Ozone Outlet Needle Valve Main Power Light Power Entry Module – OFF/ON Switch, Cord Input, Fuse Carrier Bonding/Ground Lug Fan and Fan Filter Shown: ClearWater Tech CD1500P Ozone Generator OZONE GENERATOR SPECIFICATIONS OZONE OUTPUT/SCFH 15g/h, 6% @ 6 scfh, 10PSI CD1500P 27”...
Page 26 Appendix (continued) Section A – Specifications Ozone Output LED’s Pressure Gauge CFH Gauge Reaction Chambers Drive Board and Drive Transformer - XFMR (under boards) Inline Particulate Filter Power Supply Pressure Switch 4-20mA Control Board Cover Safety Switch External Loop Remote 4-20mA Control Leads Fan and Fan Filter Air Prep Inlet Manual Ozone Output Adjustment Knob...
Page 27: Parts List
APPENDIX - Section B Parts List Air Preparation Ozone Generator OXS90 CD1500P Description Description CD2000P Compressor Inlet Filter OXS350 Reaction Chamber – Complete RCC9 CD1500P Compressor Rebuild Kit OXS356 Reaction Chamber – Complete RCC10 Pressure Relief Valve OXS361 CD2000P Dielectric Anode 2”...
Page 28: Maintenance Kit
Oxygen Concentrator – Compressor Rebuild Kit OXS361 Oxygen Concentrator – Compressor Pressure Relief Valve OXS370 Oxygen Concentrator – Replacement Cover Filter Ozone Generators ASPM246A - Maintenance Kit – CD1500P ozone generator Part # QTY Description FA40 Filter – Fan filter, element only FLT34 Filter –...
Page 29 APPENDIX - Section D Logic Schematics – CD1500P L2/N Power Entry Module With Fuses Cover Safety Switch Power Supply Power Supply Manual Ozone Output Control Remote 4-20mA Ozone Output Control Orange (+), Purple (-) External Loop Pressure Switch Drive Board...
Page 30 Appendix (continued) Logic Schematics – CD2000P L1 L2/N Power Entry Module With Fuses Cover Safety Switch Power Supply Power Supply Manual Ozone Output Control Remote 4-20mA Ozone Output Control Orange (+), Purple (-) External Loop Pressure Switch 4-20mA Drive Board Drive Board Control Board Variable...
Page 31 APPENDIX - Section E Drive Module Input Voltages Shown: Dual HO Drive Module...
Page 32 APPENDIX - Section E ClearWater Tech, LLC. Limited One-Year Warranty Summary of the Warranty ClearWater Tech, LLC (“CWT”) makes every effort to assure that its products meet high quality and durability standards and warrants the products it manufactures against defects in materials and workmanship for a period of one (1) year, commencing on the date of original shipment from CWT, with the following exceptions: 1) The warranty period shall begin on the installation date if the installation is performed within 90 days of the original shipment from CWT;...
