- Page 1 Magnetic Stripe Reader SERIES 1290 Operation Manual Version 1.0...
- Page 2 MSR JC-1290 series User’s Manual This equipment has been tested and found to comply with the limits for Class A digital device. Pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in aresidential installation.
-
Page 3: Table Of Contents
MSR JC-1290 series User’s Manual Table of Contents: Chapter 1 Appearance ................3 Chapter 2 Installation 2-1. JC-1290 KB Series ..............4 2-2. JC-1290 RS232 Series............5 2-3. JC-1290 USB Series............6 Chapter 3 Driver Installation ..............7 Chapter 4 Programming Tools 4-1. Install Programming Tool..........10 4-2. -
Page 4: Chapter 1 Appearance
MSR JC-1290 series User’s Manual CHAPTER 1 Appearance MSR 1290 RJ-45 Connector... -
Page 5: Chapter 2 Installation
MSR JC-1290 series User’s Manual Installation CHAPTER 2 2-1. JC-1290 KB serie The MD-6M side of KB cable, shall be connected to PC PS/2 Keyboard port. The MD-6F side of KB cable can be connected to normal PC keyboard, PC keyboard can work with the product together. -
Page 6: Jc-1290 Rs232 Series
MSR JC-1290 series User’s Manual 2-2. JC-1290 RS232 series The DB-9F side of RS232 cable connects to PC COM port (COM 1 or COM 2 or other COMs) , and power connects to USB . JC-1290 Touch POS 8802 RS232... -
Page 7: Jc-1290 Usb Series
MSR JC-1290 series User’s Manual 2-3. JC-1290 USB series (USB-KB & USB-RS232) Step 1: Connect to the computer Plug the USB-connector into the USB port of your computer. !! !! !!! ! ! ! Touch POS 8802 JC-1290 ! ! ! ! ! ! ! ! USB-KB USB-RS232... -
Page 8: Chapter 3 Driver Installation
MSR JC-1290 series User’s Manual CHAPTER 3 Driver Installation JC-1290 KB series : Standard PS/2 keyboard interface.(no driver needed) JC-1290 RS232 series : Standard com port interface.(no driver needed) JC-1290 USB-KB series : Standard usb keyboard interface.(no driver needed in Win2K/XP/2003/Vista ) JC-1290 USB-RS232 series : CP210x Visual COM V5.0 for Win2K/XP/2003/Vista Please refer to the following picture to install USB-RS232 driver 1290 USB Driver for Windows... - Page 9 MSR JC-1290 series User’s Manual Please select the "CP210xVCPInstaller.exe" When the setup screen appears than to select "Install" step.
- Page 10 MSR JC-1290 series User’s Manual After installation complete select “OK”. Please connect the 1290 USB-RS232 to computer, then check the device installed normally in device manager. "Silicon Labs CP210x USB to UART Bridge(COM6)" Notes: COM number may be different on each computer.
-
Page 11: Chapter 4 Programming Tools
MSR JC-1290 series User’s Manual CHAPTER 4 Programming Tool 4-1. Install Programming Tool Note: Please install Microsoft .NET Framework 2.0 first. Download Web site: http://www.microsoft.com/downloads/details.aspx? familyid=0856EACB-4362-4B0D-8EDD-AAB15C5E04F5&displaylang=zh-tw Insert CD-ROM and select "1290_Programming_Tool_V1.exe". When the setup screen appears than to select "Next" step. - Page 12 MSR JC-1290 series User’s Manual When the setup screen appears than to select "Next" step. Please select "I agree.." than to select "Next"step.
- Page 13 MSR JC-1290 series User’s Manual When the setup screen appears than to select "Next" step. When the setup screen appears than to select "Yes".
- Page 14 MSR JC-1290 series User’s Manual When the setup screen appears than to select "Start" step. When the setup screen appears than to select "Next" step.
- Page 15 MSR JC-1290 series User’s Manual After installation complete select “Exit”.
-
Page 16: Execution Programming Tool
MSR JC-1290 series User’s Manual 4-2. Execution Programming Tool Please Executive the "1290_programming_Tool" Please click the"File" on the functionality. - Page 17 MSR JC-1290 series User’s Manual Please choose the device type first, USB(Keyboard) is for example. Please Click "New" to create a new file. Please Click "Open config File" to open the saved file.
- Page 18 MSR JC-1290 series User’s Manual Please Click "Save" to save the file. Please Click "Save As" to save a another file.
- Page 19 MSR JC-1290 series User’s Manual This function can programming device form a config file. This function can save device setting to a config file.
- Page 20 MSR JC-1290 series User’s Manual This function can reset device to default value. Please choose whether to reset in this screen.
-
Page 21: Main Setting
MSR JC-1290 series User’s Manual 4-3. Main Setting Error Beep Sound: Enable / disable sound when MSR reading error. Prefix / Suffix: Enable or disable prefix / suffix for MSR data When the check box on, you can edit the prefix / suffix,every fields in up to 7 characters. Note: The format of output data is: [MSR Prefix] [Track1 data] [Track2 data] [Track3 data] [MSR Suffix]... -
Page 22: Msr Right Side Button Function
MSR JC-1290 series User’s Manual right side button function 4-4. MSR MSR Write: This Button is for write the data settings to MSR JC-1290. Set Default: This Button is for set the data to default. Load Key Setting: This Button is for load the setting from MSR device. Test: This button is for show test window. -
Page 23: Track1~3 Setting
MSR JC-1290 series User’s Manual 4-5. Track1~3 Setting Beep Sound Enable / disable sound when MSR reads the data of card track. Prefix / Suffix Enable or disable prefix / suffix for the data of card track. Start Sentinel Enable / Disable track start sentinel (Track 1 start sentinel is “% “, Track 2 / 3 start sentinel is “;... -
Page 24: Msr Iso Standard Setting
MSR JC-1290 series User’s Manual 4-6. MSR ISO Standard Setting For the ISO standard field settings, you need to set the check box of "Field Splitting Enable" for ON, then the data of card track will be outputted and follow the ISO standard fields. You can set the "Send CR"... -
Page 25: Firmware Update
MSR JC-1290 series User’s Manual 4-7. Firmware Update Special Note: The JC-1290 provides new features update or modification from the programming tool. Step 1. When you click "Open File" button will pop up the window, select the BIN file then click "Open".(Picture on the "SS-1290001-10.bin" is an example) - Page 26 MSR JC-1290 series User’s Manual Step 2. When the picture show on F/W Version after the press "Flash Firmware" button to update. Note: Please do not power off the JC-1290 or removal the usb cable when updating firmware.
-
Page 27: Switch Setting
MSR JC-1290 series User’s Manual 4-8. Switch Settings This switch is provides the user for fast settings. Default is all OFF SW1 Track data sets by software Fixed track data output: 1. Fully track data. 2. Fixed prefix: Track1 “%” , Track2 “;” , Track3 “+” 3. -
Page 28: Appendix I - Specification
MSR JC-1290 series User’s Manual Appendix I : Specifications MSR JC-1290 Model Triple-tracks: Tracks 1 & 2 & 3 Decoding Capability 7.5 to 125 cm/sec Card Reading Speed Bi-directional 300,000 passes Magnetic Head Life ISO standard 7810,7811,7812,7813 Card Format Supports Audible beep for each Status Indicator Successful reading... -
Page 29: Troubleshooting
MSR JC-1290 series User’s Manual Troubleshooting Q1. When 1290 USB plug-in the USB port, the operating system will require to install the driver? Ans: It needs to install the specialized driver of 1290 USB. After installation, it will produce a virtual COM port in the administrator. Q2: 1290 USB swipes with “Beep”... - Page 30 MSR JC-1290 series User’s Manual Q6. After connecting the cable of 1290 K keyboard to PC, the swiping data can’t show up on the screen? Ans: A. The connection of 1290 K keyboard cable should be ready before you turn on the computer. Otherwise, the keyboard device is no action. B.
