Inari 6 Quick Start Guide
Inari features, buttons & interfaces
Front
1
Charging indicator LED
OFF
not connected to charger
ORANGE
charging
GREEN
connected and fully charged
RED
charge fault
2
Front camera
3
On / Off Button
Push it once to start the tablet; push it again to enable the sleep mode. Push and
hold it to shut down the device.
4
Volume key or programmable buttons
Volume: left side to reduce volume, right side to increase volume
Buttons can be also programmed for instance to control scanner
5
Front receiver
6
Ambient Light Sensor & proximity sensor
ALS recognizes the ambient light and adjusts the display brightness if enabled in the operating
system; PS recognizes if device is held to ear or in pocket
7
Front microphone outlet
8
Front speaker
DRAFT
3
2
1
7
4
5
6
8

Advertisement

Table of Contents
loading

Related Manuals for AAVA MOBILE Inari 6

Summary of Contents for AAVA MOBILE Inari 6

  • Page 1 DRAFT Inari 6 Quick Start Guide Inari features, buttons & interfaces Front Charging indicator LED not connected to charger ORANGE charging GREEN connected and fully charged charge fault Front camera On / Off Button Push it once to start the tablet; push it again to enable the sleep mode. Push and hold it to shut down the device.

  • Page 2: Bottom Side

    DRAFT Bottom side Short Flip Charging pads USB-C 2D scanner (optional) Tablet available with or without 2D scanner Rear view Short Flip Camera flash LED 8MP camera for high resolution images & video (optional) Antenna position Tablet available with or without 8MP camera...

  • Page 3: Using The Device For The First Time

    DRAFT Replacing Battery / Adding payment terminal To replace the battery, unscrew the battery lid by rotating the lid counterclockwise. Remove the empty battery and replace it with a new one. Please pay attention to the insertion direction which is shown in the graphic below.

  • Page 4: Troubleshooting

    Connecting USB3.0 devices while being connected to a WLAN network requires it to be a 5GHz connection to maintain it. 2.4GHz networks will be disconnected on the Inari 6 side while USB3.0 devices are in use. Important Product and Safety information •...

  • Page 5: Warning Statements

    DRAFT • Power rating main battery inside flip hinge: 3.6V --- 4.8A • Power rating core battery: 3.8V --- 2.25A • Do not disconnect charger by pulling the cord. • Do not use damaged power cords or plugs. • Save energy. You can save energy by doing following. Close unused applications and data connections.

  • Page 6: Conformity Declarations

    EU Declaration of Conformity Hereby, Aava Mobile declares that the radio equipment Inari 6 is in compliance with Directive 2011/65/EU and 1999/5/EC or 2014/53/EU (2014/53/EU supersedes 1999/5/EC from 13th June 2017). The full text of the EU Declaration of Conformity is available at the following internet address: http://www.aavamobile.com/doc...

  • Page 7: Fcc Compliance Statement

    Regulatory markings, subject to certification, are applied to the device signifying the radio(s) are approved for use in the following countries: United States, Canada, and Europe . Please refer to the Aava Mobile Declaration of Conformity (DoC) for details of other country markings. This is available at http://www.aavamobile.com/doc.
  • Page 8 DRAFT This product has been tested and found to comply with the following standards: • For the worst case positions, the INARI6 is in compliance with the IC RSS 102 Issue 5 (RSS 102) and Federal Communications Commission (FCC) Guidelines (KDB) 47 C.F.R. §§ 2.1091 and 2.1093 for uncontrolled exposure.

  • Page 9: Waste Electrical And Electronic Equipment (Weee)

    Waste Electrical and Electronic Equipment (WEEE) English: For EU Customers: All products at the end of their life must be returned to Aava Mobile for recycling. For information on how to return product, please go to: http://www.aavamobile.com/weee. Français: Clients de l'Union Européenne: Tous les produits en fin de cycle de vie doivent être retournés à Aava Mobile pour recyclage.
  • Page 10 Românesc: Pentru clienţii din UE: Toate produsele, la sfârşitul duratei lor de funcţionare, trebuie returnate la Aava Mobile pentru reciclare. Pentru informaţii despre returnarea produsului, accesaţi: http://www.aavamobile.com/weee. Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske dobe vrniti podjetju Aava Mobile za reciklažo. Za informacije o vračilu izdelka obiščite: http://www.aavamobile.com/weee.
  • Page 11 Harksheider Str. 3 22399 Hamburg, Germany Tel.: +49 40 6979 5939 Aava Mobile SAS 390, avenue du Mistral ZI Athelia IV 13600 La Ciotat, France Tel.: +33 6 77 46 31 61 www.aavamobile.com © 2018 Aava Mobile Oy, All rights resevered...
